904l Stainless Steel Sheet, 904l SS Sheet, Stainless Steel 904l Sheet, SS 904l Sheet
Stainless Steel 904L Sheets are high-grade austenitic stainless steel characterized by their optimum corrosion resistance in severe conditions. These sheets are strongly resistant, low-carbon, and specially made for severe chloride conditions such as seawater and chemical processing plants. Manufactured by using hot or cold rolling methods followed by annealing, pickling, and finishing, SS 904L Sheets possess high-quality surface and mechanical properties. Nandini Steel, an ISO 9001-certified company, prides itself on being a reputable supplier of quality 904L stainless steel sheets.
We supply high-quality 904L Stainless Steel Sheet and 904L SS Sheet for various industrial applications. Our range includes Stainless Steel 904L Sheet, known for excellent corrosion resistance and durability in harsh environments.
Key Features of Stainless Steel 904L Sheets
Compared to grades like 316L, the stainless steel 904L sheet offers several superior characteristics, especially in environments with strong acids or chlorides.
- Superior Corrosion Resistance: Although both grades provide good corrosion resistance SS 904L is superior to 316L in extremely aggressive conditions like exposure to strong acids (sulfuric, phosphoric) and chloride.
- Low Carbon Content: Both 316L and 904L SS sheets are low-carbon alloys, but 904L’s low carbon content reduces the chances of intergranular corrosion even after welding.
- Higher Alloying Elements: 904L stainless steel sheet contains more Nickel (up to 28%) and extra Copper (up to 2%) than 316L which does not contain Copper. It makes 904L more resistant to sulfuric acid and chloride-caused corrosion.
- Increased Durability & Longevity: SS 904L sheets offer a longer service life in extreme environments where 316L may suffer from pitting and crevice corrosion over time.
- Greater Temperature Resistance: Stainless steel sheet 904L works better at higher temperatures up to 1150°C, whereas 316L can withstand temperatures up to 870°C – 925°C.
- Excellent Resistance to Stress Corrosion Cracking: 904L with its superior Nickel content, is much stronger in resistance against stress corrosion cracking compared to 316L, particularly in chlorine-rich or acid environments.
Compositions and Properties of SS 904L Sheets
SS 904L plates are designed with a combined set of balanced elements that impart better mechanical as well as corrosion resistance properties to the plates. The alloy has Nickel (23.0%–28.0%), Chromium (19.0%–23.0%), Molybdenum (4.0%–5.0%) and Copper (1.0%–2.0%) with only negligible Carbon content (max 0.020%).Nickel and Molybdenum make it highly corrosion-resistant against chlorides, whereas Copper increases acid resistance to sulfuric acid.The composition has a minimum yield strength of 220 MPa, tensile strength of 490 MPa, elongation of 35% and a maximum hardness of 90 HRB making the 904L stainless steel sheet a strong and versatile material.
Applications & Industries
The SS 904L sheet is applied extensively in those industries where high corrosion resistance is of paramount importance. It is applied in air pollution control systems and metallurgical processing facilities where protection from acidic and chloride-bearing atmospheres is imperative. The material excels in seawater and brackish water environments, and thus is ideal for offshore and marine engineering applications. It finds application in the pharmaceutical industry also because of its non-reactive and hygienic surface. Its versatility across various industries highlights its worth in high-performance applications.
Packaging, Testing & Delivery
We pack all 904L SS sheets securely in wooden crates, pallets and protective wrapping to avoid damage during transportation. Our sheets are thoroughly tested for quality such as ultrasonic, PMI and mechanical tests to meet international standards.We provide timely and reliable delivery services across the globe to meet your project schedules without sacrificing product quality.
Looking for a high-performance 904L stainless steel sheet for your next project? Get in touch with us today for competitive pricing, expert consultation and fast delivery. Contact us now to request a quote or more product details!
Other Types Stainless Steel 904L Sheets
SS 904L Shim Sheets
SS 904L Perforated Sheet
SS 904L Hot Rolled Sheet
SS 904L CR Sheets
Stainless Steel 904L Strip
Stainless Steel 904L Foils
Matt PVC SS 904L Sheet
2B SS 904L Sheets
Stainless Steel 904L Sheets Specification
Sheet Specifications: ASTM A240 / ASME SA240
Dimensions: ASTM, ASME, and API
Thickness Range: 4mm to 100mm
Width: 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length: 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Finish: 2B, 2D, BA, No.1, No.4, No.8, 8K, mirror, chequered, embossed, hairline, sand blast, brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated), etc
Hardness: Soft, Hard, Half Hard, Quarter Hard, Spring Hard
Form: Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange), etc
Dimensions: ASTM, ASME, and API
Thickness Range: 4mm to 100mm
Width: 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length: 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Finish: 2B, 2D, BA, No.1, No.4, No.8, 8K, mirror, chequered, embossed, hairline, sand blast, brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated), etc
Hardness: Soft, Hard, Half Hard, Quarter Hard, Spring Hard
Form: Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange), etc
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
| SS 904L | 0.020 max | 2.00 max | 1.00 max | 0.040 max | 0.030 max | 19.00 – 23.00 | 4.00 – 5.00 max | 23.00 – 28.00 | 1.00 – 2.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | BS | KS | AFNOR | EN | JIS |
| SS 904L | 1.4539 | N08904 | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 | SUS 904L |
Stainless Steel 904L Sheet Thickness Chart
| Thickness | Thickness | Size Range | Surface Area per Unit weight | Approx Weight per Sheet | ||
| inches | mm | lbs/ft² | kg/m² | lbs | kg | |
| 0.015 | 0.381 | 36 x 96 | 0.630 | 3.07566 | 15.12 | 6.84936 |
| 0.015 | 0.381 | 36 x 120 | 0.630 | 3.07566 | 18.90 | 8.5617 |
| 0.0178 | 0.45212 | 36 x 96 | 0.756 | 3.690792 | 18.15 | 8.22195 |
| 0.0178 | 0.45212 | 36 x 120 | 0.756 | 3.690792 | 22.68 | 10.27404 |
| 0.0178 | 0.45212 | 48 x 96 | 0.756 | 3.690792 | 24.19 | 10.95807 |
| 0.0178 | 0.45212 | 48 x 120 | 0.756 | 3.690792 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 30 x 96 | 1.008 | 4.921056 | 20.16 | 9.13248 |
| 0.0235 | 0.5969 | 30 x 120 | 1.008 | 4.921056 | 25.20 | 11.4156 |
| 0.0235 | 0.5969 | 36 x 96 | 1.008 | 4.921056 | 24.19 | 10.95807 |
| 0.0235 | 0.5969 | 36 x 120 | 1.008 | 4.921056 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 36 x 144 | 1.008 | 4.921056 | 36.29 | 16.43937 |
| 0.0235 | 0.5969 | 48 x 96 | 1.008 | 4.921056 | 32.26 | 14.61378 |
| 0.0235 | 0.5969 | 48 x 120 | 1.008 | 4.921056 | 40.32 | 18.26496 |
| 0.0235 | 0.5969 | 48 x 144 | 1.008 | 4.921056 | 48.39 | 21.92067 |
| 0.0291 | 0.73914 | 30 x 96 | 1.260 | 6.15132 | 25.20 | 11.4156 |
| 0.0291 | 0.73914 | 30 x 120 | 1.260 | 6.15132 | 31.50 | 14.2695 |
| 0.0291 | 0.73914 | 36 x 96 | 1.260 | 6.15132 | 30.24 | 13.69872 |
| 0.0291 | 0.73914 | 36 x 120 | 1.260 | 6.15132 | 37.80 | 17.1234 |
| 0.0291 | 0.73914 | 36 x 144 | 1.260 | 6.15132 | 45.37 | 20.55261 |
| 0.0291 | 0.73914 | 48 x 96 | 1.260 | 6.15132 | 40.32 | 18.26496 |
| 0.0291 | 0.73914 | 48 x 120 | 1.260 | 6.15132 | 50.41 | 22.83573 |
| 0.0291 | 0.73914 | 48 x 144 | 1.260 | 6.15132 | 60.49 | 27.40197 |
| 0.0355 | 0.9017 | 30 x 96 | 1.512 | 7.381584 | 30.24 | 13.69872 |
| 0.0355 | 0.9017 | 30 x 120 | 1.512 | 7.381584 | 37.80 | 17.1234 |
| 0.0355 | 0.9017 | 36 x 96 | 1.512 | 7.381584 | 36.29 | 16.43937 |
Weight Per Stainless Steel 904L Sheet
| THICKNESS IN MM | SIZE IN MM | WEIGHT KG/M2 | ||
| 2000 X 1000 | 2500 X 1250 | 3000 X 1500 | ||
| 0.18 | 2.88 | – | – | 1.44 |
| 0.20 | 3.20 | – | – | 1.60 |
| 0.22 | 3.52 | – | – | 1.76 |
| 0.24 | 3.84 | – | – | 1.92 |
| 0.27 | 4.32 | – | – | 2.16 |
| 0.28 | 4.48 | – | – | 2.24 |
| 0.32 | 5.12 | – | – | 2.56 |
| 0.38 | 6.08 | – | – | 3.04 |
| 0.44 | 7.04 | 11.00 | – | 3.52 |
| 0.50 | 8.00 | 12.50 | – | 4.00 |
| 0.56 | 8.96 | 14.00 | – | 4.48 |
| 0.63 | 10.08 | 15.75 | – | 5.04 |
| 0.75 | 12.00 | 18.75 | – | 6.00 |
| 0.88 | 14.08 | 22.00 | – | 7.04 |
| 1.00 | 16.00 | 25.00 | 36.00 | 8.00 |
| .1.13 | 18.08 | 28.25 | 40.00 | 9.04 |
| 1.25 | 20.00 | 31.25 | 45.00 | 10.00 |
| 1.38 | 22.03 | 34.50 | 50.00 | 72.00 |
| 1.50 | 24.00 | 37.50 | 54.00 | 12.00 |
| 1.75 | 28.00 | 43.75 | 63.00 | 14.00 |
| 2.00 | 32.00 | 50.00 | 72.00 | 16.00 |
| 2.25 | 36.00 | 56.25 | 81.00 | 18.00 |
| 2.50 | 40.00 | 62.50 | 90.00 | 20.00 |
| 2.75 | 44.00 | 68.75 | 99.00 | 22.00 |
| 3.00 | 48.00 | 75.00 | 108.00 | 24.00 |
| 3.25 | 52.00 | 81.25 | 117.00 | 26.00 |
| 3.50 | 56.00 | 87.50 | 126.00 | 28.00 |
| 3.75 | 60.00 | 93.75 | 135.00 | 30.00 |
| 4.00 | 64.00 | 100.00 | 144.00 | 32.00 |
| 4.25 | 68.00 | 106.25 | 153.00 | 34.00 |
| 4.50 | 72.00 | 112.50 | 162.00 | 36.00 |
| 5.00 | 80.00 | 125.00 | 180.00 | 40.00 |
| 5.50 | 88.00 | 137.50 | 198.00 | 44.00 |
| 6.00 | 96.00 | 150.00 | 216.00 | 48.00 |
| 6.50 | 104.00 | 162.50 | 234.00 | 52.00 |
| 7.00 | 112.00 | 175.00 | 252.00 | 56.00 |
| 7.50 | 120.00 | 187.50 | 270.00 | 60.00 |
| 8.00 | 128.00 | 200.00 | 288.00 | 64.00 |
