We provide top-quality 347 Stainless Steel Sheet, 347 Stainless Sheet, and are recognized as reliable 347 Stainless Steel Sheet Suppliers for various industrial requirements.
Nandini Steel specializes in offering superior quality 347 Stainless Steel Sheets that guarantee optimum performance as well as reliability. As an ISO 9001:2015 certified, we adhere to stringent quality management standards, ensuring that each product meets international benchmarks. Our 347 stainless steel sheet is a type of austenitic chromium-nickel stainless steel stabilized with columbium and tantalum, that resists corrosion when the temperature is high. The sheets are produced by hot or cold rolling, then annealing and pickling for increased durability.
Nandini Steel is a trusted supplier of 347 Stainless Steel Sheet, 347 Stainless Sheet, and a leading name among 347 Stainless Steel Sheet Suppliers, offering quality materials for high-temperature applications.
Key Features of 347 Stainless Steel Sheets
- Superior High-Temperature Resistance – When compared to similar grades such as SS 321, SS 347 has high maintaining strength and oxidation resistance at temperatures up to 870°C, because of enhanced niobium stabilization.
- Enhanced Corrosion Resistance – While many austenitic stainless steels are prone to intergranular corrosion, SS 347 outperforms its counterparts by resisting this deterioration, making it ideal for prolonged exposure to harsh, high-temperature environments.
- Increased Weldability – The addition of niobium in SS 347 ensures that carbide precipitation is not encountered during welding, contrary to other grades that may experience sensitization problems, thus obtaining strong and dependable welds.
- Better Mechanical Properties – SS 347 exhibits greater tensile strength, creep resistance, and overall longevity than grades such as SS 316 and SS 321, with improved performance under mechanical load.
- Improved Fabrication and Formability – SS 347 provides good formability and ease of fabrication, with improved manufacturing ease and lower manufacturing costs compared to similar grades.
Composition and Properties of SS 347 Sheets
The chemical composition of SS 347 is 18-20% Chromium, 9-13% Nickel, 0.08% Carbon, 0.75% Silicon, 2.0% Manganese, and Nb (Columbium) + Tantalum at 10x C minimum. The high chromium (Cr) is added to increase the oxidation resistance, whereas nickel (Ni) content is used to increase the overall corrosion resistance, particularly in acidic environments. The niobium (Nb) stabilization prevents precipitation of carbides, thereby maintaining weldability. Considering mechanical properties, SS 347 has a tensile strength of 515 MPa, yield strength of 205 MPa and elongation of 40%, thereby ensuring reliability in harsh conditions. This unique combination of chemical and mechanical properties makes it a superior choice for high-temperature and high-stress environments.
Applications of stainless steel 347 sheet
Our ASTM A240 SS 321 sheet finds extensive applications across industries because of its superior resistance to high temperatures and oxidation. Typically used in heat exchangers, exhaust manifolds, boiler tubes, furnace components, and chemical processing equipment. They are a must in aerospace, marine, food processing, and petrochemical industries where strength and resistance to harsh environments are paramount.
Packaging, Testing & Delivery
We deliver 347 SS Sheets safely and securely using tough wooden cases or pallets so that it cannot be damaged or rust. Every shipment contains vital documentation for quality control, including reports on quality measurements, fumigation reports, laboratory test reports, guarantee letters, heat treatment charts and a commercial invoice.
Looking for the best 347 Stainless Steel Sheet? Nandini Steel offers premium-quality products with guaranteed durability and performance. Contact us today for a competitive quote and expert assistance!
Other Types Stainless Steel 347 Sheets
SS 347 Shim Sheets
SS 347 Perforated Sheet
SS 347 Hot Rolled Sheet
SS 347 CR Sheets
Stainless Steel 347 Strip
Stainless Steel 347 Foils
Matt PVC SS 347 Sheet
2B SS 347 Sheets
Stainless Steel 347 Sheets Specification
Specifications: ASTM A240 / ASME SA240
Dimensions: ASTM, ASME, and API
Width: 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Thickness: 4mm – 100mm
Length: 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface Finish: 2B, 2D, BA, No.1, No.4, No.8, 8K, mirror, chequered, embossed, hairline, sand blast, brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated), etc
Hardness: Soft, Hard, Half Hard, Quarter Hard, Spring Hard
Form: Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange), etc
Dimensions: ASTM, ASME, and API
Width: 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Thickness: 4mm – 100mm
Length: 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface Finish: 2B, 2D, BA, No.1, No.4, No.8, 8K, mirror, chequered, embossed, hairline, sand blast, brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated), etc
Hardness: Soft, Hard, Half Hard, Quarter Hard, Spring Hard
Form: Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange), etc
| Grade | C | Mn | Si | P | S | Cr | Cb | Ni | Fe |
| SS 347 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 20.00 | 10xC – 1.10 | 9.00 – 13.00 | 62.74 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | GOST | EN | JIS |
| SS 347 | 1.4550 | S34700 | 08Ch18N12B | X6CrNiNb18-10 | SUS 347 |
Stainless Steel 347 Sheet Thickness Chart
| Thickness | Thickness | Size Range | Surface Area per Unit weight | Approx Weight per Sheet | ||
| inches | mm | lbs/ft² | kg/m² | lbs | kg | |
| 0.015 | 0.381 | 36 x 96 | 0.630 | 3.07566 | 15.12 | 6.84936 |
| 0.015 | 0.381 | 36 x 120 | 0.630 | 3.07566 | 18.90 | 8.5617 |
| 0.0178 | 0.45212 | 36 x 96 | 0.756 | 3.690792 | 18.15 | 8.22195 |
| 0.0178 | 0.45212 | 36 x 120 | 0.756 | 3.690792 | 22.68 | 10.27404 |
| 0.0178 | 0.45212 | 48 x 96 | 0.756 | 3.690792 | 24.19 | 10.95807 |
| 0.0178 | 0.45212 | 48 x 120 | 0.756 | 3.690792 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 30 x 96 | 1.008 | 4.921056 | 20.16 | 9.13248 |
| 0.0235 | 0.5969 | 30 x 120 | 1.008 | 4.921056 | 25.20 | 11.4156 |
| 0.0235 | 0.5969 | 36 x 96 | 1.008 | 4.921056 | 24.19 | 10.95807 |
| 0.0235 | 0.5969 | 36 x 120 | 1.008 | 4.921056 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 36 x 144 | 1.008 | 4.921056 | 36.29 | 16.43937 |
| 0.0235 | 0.5969 | 48 x 96 | 1.008 | 4.921056 | 32.26 | 14.61378 |
| 0.0235 | 0.5969 | 48 x 120 | 1.008 | 4.921056 | 40.32 | 18.26496 |
| 0.0235 | 0.5969 | 48 x 144 | 1.008 | 4.921056 | 48.39 | 21.92067 |
| 0.0291 | 0.73914 | 30 x 96 | 1.260 | 6.15132 | 25.20 | 11.4156 |
| 0.0291 | 0.73914 | 30 x 120 | 1.260 | 6.15132 | 31.50 | 14.2695 |
| 0.0291 | 0.73914 | 36 x 96 | 1.260 | 6.15132 | 30.24 | 13.69872 |
| 0.0291 | 0.73914 | 36 x 120 | 1.260 | 6.15132 | 37.80 | 17.1234 |
| 0.0291 | 0.73914 | 36 x 144 | 1.260 | 6.15132 | 45.37 | 20.55261 |
| 0.0291 | 0.73914 | 48 x 96 | 1.260 | 6.15132 | 40.32 | 18.26496 |
| 0.0291 | 0.73914 | 48 x 120 | 1.260 | 6.15132 | 50.41 | 22.83573 |
| 0.0291 | 0.73914 | 48 x 144 | 1.260 | 6.15132 | 60.49 | 27.40197 |
| 0.0355 | 0.9017 | 30 x 96 | 1.512 | 7.381584 | 30.24 | 13.69872 |
| 0.0355 | 0.9017 | 30 x 120 | 1.512 | 7.381584 | 37.80 | 17.1234 |
| 0.0355 | 0.9017 | 36 x 96 | 1.512 | 7.381584 | 36.29 | 16.43937 |
Weight Per Stainless Steel 347 Sheet
| THICKNESS IN MM | SIZE IN MM | WEIGHT KG/M2 | ||
| 2000 X 1000 | 2500 X 1250 | 3000 X 1500 | ||
| 0.18 | 2.88 | – | – | 1.44 |
| 0.20 | 3.20 | – | – | 1.60 |
| 0.22 | 3.52 | – | – | 1.76 |
| 0.24 | 3.84 | – | – | 1.92 |
| 0.27 | 4.32 | – | – | 2.16 |
| 0.28 | 4.48 | – | – | 2.24 |
| 0.32 | 5.12 | – | – | 2.56 |
| 0.38 | 6.08 | – | – | 3.04 |
| 0.44 | 7.04 | 11.00 | – | 3.52 |
| 0.50 | 8.00 | 12.50 | – | 4.00 |
| 0.56 | 8.96 | 14.00 | – | 4.48 |
| 0.63 | 10.08 | 15.75 | – | 5.04 |
| 0.75 | 12.00 | 18.75 | – | 6.00 |
| 0.88 | 14.08 | 22.00 | – | 7.04 |
| 1.00 | 16.00 | 25.00 | 36.00 | 8.00 |
| .1.13 | 18.08 | 28.25 | 40.00 | 9.04 |
| 1.25 | 20.00 | 31.25 | 45.00 | 10.00 |
| 1.38 | 22.03 | 34.50 | 50.00 | 72.00 |
| 1.50 | 24.00 | 37.50 | 54.00 | 12.00 |
| 1.75 | 28.00 | 43.75 | 63.00 | 14.00 |
| 2.00 | 32.00 | 50.00 | 72.00 | 16.00 |
| 2.25 | 36.00 | 56.25 | 81.00 | 18.00 |
| 2.50 | 40.00 | 62.50 | 90.00 | 20.00 |
| 2.75 | 44.00 | 68.75 | 99.00 | 22.00 |
| 3.00 | 48.00 | 75.00 | 108.00 | 24.00 |
| 3.25 | 52.00 | 81.25 | 117.00 | 26.00 |
| 3.50 | 56.00 | 87.50 | 126.00 | 28.00 |
| 3.75 | 60.00 | 93.75 | 135.00 | 30.00 |
| 4.00 | 64.00 | 100.00 | 144.00 | 32.00 |
| 4.25 | 68.00 | 106.25 | 153.00 | 34.00 |
| 4.50 | 72.00 | 112.50 | 162.00 | 36.00 |
| 5.00 | 80.00 | 125.00 | 180.00 | 40.00 |
| 5.50 | 88.00 | 137.50 | 198.00 | 44.00 |
| 6.00 | 96.00 | 150.00 | 216.00 | 48.00 |
| 6.50 | 104.00 | 162.50 | 234.00 | 52.00 |
| 7.00 | 112.00 | 175.00 | 252.00 | 56.00 |
| 7.50 | 120.00 | 187.50 | 270.00 | 60.00 |
| 8.00 | 128.00 | 200.00 | 288.00 | 64.00 |
