Our dedication to excellence is supported by our ISO 9001:2015 certification, guaranteeing rigorous quality control, and compliance with industry standards. ASME SA / ASTM 516 GR 70(NACE+HIC) plate is engineered for high-pressure use and it is a popular choice in industries demanding superior resistance to hydrogen-induced cracking (HIC) and NACE compliance. These plates are manufactured in strict accordance with national and international standards, ensuring top-tier quality and performance.
A516 Gr 70 HIC Resistant Steel Plate Supplier, Suppliers of ASTM A516 Grade 70 NACE Carbon Steel Plates, NACE HIC Tested A516 Grade 70 Boiler Plate Stockist, ASME SA516 GR. 70 HIC Pressure Vessels Plate in Mumbai, India.
Key Features of ASME SA/ASTM A516 GR 70 (NACE+HIC) Plate.
- Superior Resistance: ASME SA 516 GR 70 carbon steel plate is much better than regular carbon steel plates at resisting damage from sulfide stress and hydrogen-induced cracking (HIC).
- High Tensile Strength: Due to its superior mechanical properties, it performs better than SA516 Grade 60 and offers increased durability in high-pressure conditions.
- Versatile Applications: Suitable for pressure vessels and boilers, whereby their performance in the oil, gas and petrochemical industries is long-lived.
- Excellent Toughness: Designed to withstand low-temperature environments, offering better impact resistance than lower grades.
- Superior Weldability: Its composition allows for smooth fabrication and welding, reducing operational downtime.
Compositions and Properties of ASME SA / ASTM A516 GR 70(NACE+HIC) Plate
Our ASME SA / ASTM A516 GR 70(NACE+HIC) plate is made with a precise balance of elements to ensure superior strength and resistance. It’s 0.26–0.30% carbon to make it easier to weld, 0.60–0.90% manganese to add toughness and 0.15–0.40% silicon to boost strength and help resist corrosion. The plate has minimal phosphorus and sulfur (0.025% max) to reduce cracking risks. Nickel (0.50–1.50%) is added to improve corrosion resistance. On the mechanical side the plate has a tensile strength of 485 MPa and a yield strength of 275 MPa, which makes it a good fit for high-pressure applications. With excellent impact toughness, it can endure extreme temperatures and is ideal for pressure vessels in sectors like oil and gas and petrochemicals.
Applications of ASME SA / ASTM A516 GR 70 (NACE+HIC) Plate
ASME SA / ASTM A516 GR 70 (NACE+HIC) plates are commonly used in a range of industries, including power generation, gas processing, and petrochemicals. These plates are specially designed for oil drilling firms, heat exchangers, condensers, and seawater equipment to provide long-term reliability in high temperatures and pressures. With high tensile strength and resistance to impact, they are the best choice for applications requiring exceptional mechanical performance. The ASME SA516 GR 70 carbon steel plate is tested to adhere to industry standards.
Packaging & Testing
To ensure the highest product quality, we follow strict packaging and testing protocols. Our ASME SA / ASTM A516 GR 70(NACE+HIC) plate is properly packed in wooden boxes or cases to avoid damage or corrosion during shipping. Every package is properly labeled with information like product name, size, length and specifications for easy identification. Additionally, we conduct rigorous quality tests, including ultrasonic testing, impact testing, and chemical composition analysis-to make sure that each plate meets the industry standards before it is delivered.
Get the Best ASME SA / ASTM A516 GR 70(NACE+HIC) Plate from Nandini Steel, offers premium-grade pressure vessel plates at competitive prices, ensuring durability, reliability, and superior performance. Contact us today for custom sizes, bulk orders, and quick delivery to meet your industrial requirements!
Other Types of ASME SA / ASTM A516 GR 70 (NACE + HIC) Plates
SA 516 GR.70 Dual Certified HIC Nace Tested Plates
SA 516 GR.70 NACE + HIC Boiler Quality Steel Plate
SA 516 GR.70 NACE + HIC Plate Manufacturers
ASME SA 516 GR.70 Nace MR-0103 Plates
ASME SA / ASTM A516 GR 70 (NACE + HIC) Plates Specification
Standard : ASTM A516 / ASME SA516
Width : 1000mm-4500mm
Thickness : 5mm-150mm
Length : 3000mm -18000mm.
Impact tested : -52° C
Process : Hot-Rolled (HR)
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V | C.E./td> |
| 0.10/ 0.22 | 0.6 | 1/ 1.5 | 0.010 | 0.002 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 | 0.420 (max) |
| Tensile strength MPa (ksi) | Yield strength MPa (ksi) | Elongation min, % 200 mm (8 in) | Elongation min, % 50 mm (2 in) |
| 490-260 (70-90) | 265 (38) | 17 | 21 |
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-224-490A/B | EN10028 P355GH | A/SA516 – Grade 70 | – |
ASME SA / ASTM A516 GR 70 (NACE + HIC) Plates Thickness Chart
| Thickness (mm) | Thickness (inches) |
| 3 mm | 0.118 in |
| 4 mm | 0.157 in |
| 5 mm | 0.197 in |
| 6 mm | 0.236 in |
| 8 mm | 0.315 in |
| 10 mm | 0.394 in |
| 12 mm | 0.472 in |
| 16 mm | 0.630 in |
| 20 mm | 0.787 in |
| 25 mm | 0.984 in |
| 30 mm | 1.181 in |
| 32 mm | 1.260 in |
| 40 mm | 1.575 in |
| 50 mm | 1.969 in |
| 60 mm | 2.362 in |
| 70 mm | 2.756 in |
| 80 mm | 3.150 in |
| 100 mm | 3.937 in |
Weight Per ASME SA / ASTM A516 GR 70 (NACE + HIC) Plates
| Thickness (mm) | Weight (kg/m²) | Weight (kg/ft²) |
| 3 mm | 23.55 | 4.82 |
| 4 mm | 31.40 | 6.44 |
| 5 mm | 39.25 | 8.06 |
| 6 mm | 47.10 | 9.68 |
| 8 mm | 62.80 | 12.90 |
| 10 mm | 78.50 | 16.13 |
| 12 mm | 94.20 | 19.35 |
| 16 mm | 125.60 | 25.80 |
| 20 mm | 157.00 | 32.26 |
| 25 mm | 196.25 | 40.32 |
| 30 mm | 235.50 | 48.38 |
| 40 mm | 314.00 | 64.52 |
| 50 mm | 392.50 | 80.65 |
| 60 mm | 471.00 | 96.78 |
| 70 mm | 549.50 | 112.91 |
| 80 mm | 628.00 | 129.03 |
| 100 mm | 785.00 | 161.30 |
