Nandini Steel is a trusted ASME SA -516 Grade 60 plate supplier based in Mumbai, India. We supply SA 516 Gr. 60 carbon steel plates, also recognised as ASME SA-516 Grade 60, for pressure vessel, boiler and storage tank fabrication. Every plate ships with a mill test certificate per EN 10204 3.1/3.2 under our ISO 9001:2015-certified quality system.
These pressure vessel quality (PVQ) plates offer easy welding and good impact toughness for moderate and low temperatures. The carbon steel uses carefully controlled levels of carbon (0.21-0.27% depending on thickness), manganese (0.85-1.20%), and silicon (0.15-0.40%) to give a good balance of strength and weldability. The plates provide a tensile strength of 415-550 MPa and a minimum yield strength of 220 MPa, making SA 516 Grade 60 a reliable choice for pressure vessels and boilers. Thickness ranges from 4.78 mm to 150 mm in as-rolled or normalised condition, with custom cutting to size.
We stock these plates in compliance with ASME SA-516 and ASTM A516/A516M standards. Contact us for stock availability or a competitive quotation on SA-516 Grade 60 PVQ plates.
ASME SA-516 Grade 60 Plate Specifications
ASME SA-516 Grade 60 plate is supplied to the following dimensional and material specifications. The table below covers all key parameters.
Plates are available in as-rolled and normalised conditions per specification requirements.
| Parameter | Value | |||||
| Standard | ASME SA-516 / ASTM A516 | |||||
| Thickness | 4.78 mm to 150 mm (3/16″ to 6″) | |||||
| Width | Up to 3,300 mm (130″) | |||||
| Length | Up to 12,000 mm (480″); custom lengths available | |||||
| Condition | As-Rolled (thickness below 40 mm); Normalised (thickness 40 mm and above) | |||||
| Surface | Mill finish | |||||
| Testing | Mill Test Certificate per EN 10204 3.1 / 3.2; HIC/NACE testing available on request | |||||
| Edge | Mill edge, sheared, or flame-cut per client specification | |||||
Other Types of SA 516 Gr. 60 Plate
ASTM A516 Boiler Quality Plates
ASTM A515 Boiler Quality Plate
SA 516 Boiler Quality Plate
SA387 Boiler Quality Plates
ASME SA-516 Grade 60 Plate Chemical Composition
| Element | Carbon (C) | Manganese (Mn) | Phosphorus (P) | Sulphur (S) | Silicon (Si) |
| Gr. 60 Max / Range | 0.21% max (t ≤ 12.5 mm); 0.23% max (12.5–50 mm); 0.25% max (50–100 mm); 0.27% max (above 100 mm) | 0.85–1.20% | 0.035% max | 0.035% max | 0.15–0.40% |
ASME SA516 Grade 60 Plate Mechanical Properties
| Property | Tensile Strength | Yield Strength (min) | Elongation in 2″ (min) | Elongation in 8″ (min) |
| Imperial | 60–80 ksi | 32 ksi | 25% | 21% |
| Metric | 415–550 MPa | 220 MPa | 25% | 21% |
SA 516 Gr. 60 Plate Equivalent Grades
The table below helps global buyers cross-reference their local specification of ASTM A516 Grade 60 plate, also designated UNS K02100.
SA-516 Gr. 60 (UNS K02100) plates can be certified to both ASTM and ASME on one test certificate. We also offer dual-certified 60/70N plates to shorten delivery and simplify inventory.
| Country / Standard | Designation | |||||
| USA (UNS) | UNS K02100 | |||||
| Europe (EN) | EN 10028-2 P265GH | |||||
| Werkstoff (W.Nr.) | 1.0425 | |||||
| Japan (JIS) | JIS G3118 SGV410 | |||||
| China (GB) | GB 713 Q245R | |||||
| India (IS) | IS 2002 Grade 2 | |||||
| Germany (DIN) | DIN 17155 HII | |||||
| UK (BS) | BS 1501-161-430A | |||||
ASME SA516 Grade 60 Plate Industrial Applications
Oil & Gas and Petrochemical
Refineries and petrochemical plants use SA516-60 plates in cold service. For sour service, plates must be HIC-tested and supplied to NACE MR0175 / ISO 15156 requirements.
Power Generation
Boiler drums, steam generators, and economiser headers in power plants use SA 516 Grade 60 plates for their toughness at low temperatures.
Storage Tanks (API 650 / API 620)
API 650 and API 620 storage tanks often use 516-60 plate for shells, annular rings and bottoms because its strength and flexibility make forming and rolling easier.
SA 516 Gr. 60 Plate Sizes
The standard stock sizes we carry for SA 516 Gr. 60 plate are listed below.
We offer SA 516 Gr. 60 plates from 3/16″ (4.78 mm) to 6″ (150 mm) thick, including non-standard widths and lengths with MOQ, plus custom-cut sizes to your specifications.
| Thickness (inches) | Width (inches) | Length (inches) | ||||
| 3/16″ | 96 | 240 / 480 | ||||
| 1/4″ | 96 / 120 | 240 / 480 | ||||
| 5/16″ | 96 / 120 | 240 / 480 | ||||
| 3/8″ | 96 / 120 | 240 / 480 | ||||
| 1/2″ | 96 / 120 | 240 / 480 | ||||
| 5/8″ | 96 / 120 | 240 / 480 | ||||
| 3/4″ | 96 / 120 | 240 / 480 | ||||
| 7/8″ | 96 / 120 | 240 / 480 | ||||
| 1″ | 96 / 120 | 240 / 480 | ||||
| 1-1/4″ | 96 / 120 | 240 / 480 | ||||
| 1-1/2″ | 96 / 120 | 240 / 480 | ||||
| 2″ | 96 / 120 | 240 / 480 | ||||
| 2-1/2″ | 96 / 120 | 240 / 480 | ||||
| 3″ | 96 / 120 | 240 / 480 | ||||
| 4″ | 96 / 120 | 240 | ||||
| 5″ | 96 | 240 | ||||
| 6″ | 96 | 240 | ||||
