Inconel 625 Sheet Manufacturer

We Offer Premium Inconel 625 Sheet, 625 Inconel Alloy Sheet, and Grade 625 Inconel Sheets – Available in Various Sizes and Finishes

Inconel 625 Sheet is a high-performance nickel-based alloy known for its exceptional strength, corrosion resistance, and thermal stability. Nandini Steel is a reputable supplier of high-quality Inconel 625 Sheet, which offers high-performance solutions suitable for diverse industrial applications. This alloy finds great use in extreme environments where resistance to oxidation, high temperatures, and mechanical stress is required. The sheets are produced using hot or cold rolling methods, it go through heat treatment to improve their mechanical properties. Our dedication to quality, accuracy and customer satisfaction makes us a first choice for industries looking for reliable and durable alloy sheets.

Nandini Steel is a Trusted Supplier of Inconel 625 Sheet, Grade 625 Inconel Sheets, and Inconel 625 Hot Rolled Sheet for High-Performance Applications

Key Features of Inconel 625 Sheet

Better Corrosion Resistance: Inconel 625 Sheet has better resistance to oxidation, pitting, and crevice corrosion compared to Inconel 600 and is therefore well suited for use in marine and chemical applications.
High-Temperature Strength: With a melting point of around 1350°C, it outperforms Inconel 600, which has a lower temperature threshold. This makes Inconel 625 Sheet an ideal material for aerospace and heat exchanger uses.
Superior Weldability: In contrast to other nickel alloys, Inconel 625 Sheet does not need heat treatment after welding enabling easy fabrication in intricate structures.
Superior Fatigue Strength: With better fatigue strength than Inconel 600 it is very well suited for applications that involve mechanical stress and vibrations.
Non-Magnetic Properties: Its non-magnetic properties guarantee applicability in electrical and instrumentation applications where magnetic interference should be avoided.

Composition and Properties of Inconel 625 Sheet

The superior performance of Inconel 625 Sheet is attributed to its unique composition, including Nickel (58% min), Chromium (20-23%), Molybdenum (8-10%), and Niobium (3.15-4.15%). The high content of nickel and chromium gives excellent oxidation and corrosion resistance, whereas molybdenum and niobium contribute to tensile strength as well as creep resistance These properties make it a top choice for industries requiring high durability under extreme conditions. Moreover, the properties of tensile strength (930 MPa), yield strength (517 MPa), and elongation (42%) provide remarkable formability as well as toughness.

Its high fatigue strength coupled with a low coefficient of thermal expansion makes this material very resistant to cracking under stress. The Brinell hardness is 207 HB and the density is 8.44 g/cm³, hence it performs effectively for a long time in harsh environments while preserving the structure under cyclic loading and extreme pressures.

Applications of Inconel 625 She

An Inconel 625 sheet is used where heat, load, and corrosive media meet, and failure is not an option.

Aerospace and Turbine Components: Turbine engine housings and exhaust parts rely on this material because it holds its strength well past 800°C. Engineers comparing it against Inconel 718 Sheet for aerospace brackets often settle on 625 for its weldability alone.
Marine and Seawater Systems: Chloride-rich seawater eats through most alloys within a few seasons. Inconel 625 resists pitting and crevice attack in these conditions, which is why shipbuilders specify it for propeller shafts and subsea fasteners.
Chemical Processing and Power Plants: Reactor vessels, scrubbers, and flue gas ducts see acids and cyclic thermal loads at once. The 625 Inconel Alloy Sheet handles both without cracking, and the same base metal shows up in Inconel 625 Pipe for connected piping runs.
Oil and Gas, Deep-Sea Service: Downhole tools and deep-sea wellhead components face pressure and sour gas together. Grade 625 Inconel sheets stand up to sulfide stress cracking better than standard duplex grades in these wells.
Nuclear and Automotive Use: Nuclear reactor internals and select automotive exhaust parts use this alloy where fatigue resistance under vibration matters more than raw cost.

Packaging, Testing & Delivery

To ensure product integrity, we securely pack inconel 625 sheets in wooden crates or pallets, preventing damage during transit. We perform quality tests, such as hardness, tensile, and corrosion resistance tests, to ensure excellent performance. We are ISO 9001:2015 (Quality Management System) certified to ensure high quality in production and supply. With a streamlined logistics system, we ensure prompt and safe delivery to domestic and international clients.

Order the Best Quality Inconel 625 Sheet Today! Upgrade your industrial processes with our best quality Inconel 625 Sheet. Contact Nandini Steel today for the best prices and top-quality alloy sheets customized to your precise needs!

Other Types Inconel 625 Sheets

Inconel 625 Shim Sheets

Inconel 625 Hot Rolled Sheet

Inconel 625 CR Sheets

Inconel 625 Strip

Inconel 625 Sheets Specification

Sheet Specifications: ASTM B443 / ASME SB443, BS EN 10088-2, EN 10028-7, IS 6911
Dimensions: MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc
Size Range: Cold Rolled: 0.5–6.4 mm, Hot Rolled: 3.0–10.0 mm
Thickness Range: 0.3 mm to 120 mm
Width: 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length: 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Tolerances (width/thickness): EN 10258 / DIN 59381, EN 10151, EN 10088
Finish: 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR)
Hardness: Half Hard, Soft, Hard, Quarter Hard, Spring Hard
Form: Sheet, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Soft Annealed, Descaled, Sheared, Annealed
Value Added Service: Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication etc.
Profiling: Plasma Plate Cutting, Laser Plate Cutting, Oxy-propane Flame Cutting

Inconel 625 Sheets Chemical Composition

Grade	C	Mn	Si	S	Cu	Fe	Ni	Cr
Inconel 625	0.10 max	1.00 max	0.50 max	0.015max	1.00 max	Balance	58.0 – 63.0	21.0 – 25.0

Mechanical Properties of Inconel 625 Sheets

Alloy and state	tensile strengthRm N/mm2	Yield StrengthRPO.2N/mm2	ExtensibilityA5%	Brinell hardnessHB
annealing treatment	650	300	30	–
solid solution treatment	600	240	30	=220

Equivalent Grades For Inconel 625 Sheets

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
Inconel 625	2.4856	N06625	NCF 625	NA 49	XH60BT	NC23FeA	NiCr23Fe

Contact us to get a quick quote

If you require any further information about our Inconel 625 Sheets or any other product, please do not hesitate to contact us.

Call Now

Mail Us

Inconel 625 Sheets Thickness Chart

Thickness	Thickness	Size Range	Surface Area per Unit weight		Approx Weight per Sheet
inches	mm		lbs/ft²	kg/m²	lbs	kg
0.015	0.381	36 x 96	0.630	3.07566	15.12	6.84936
0.015	0.381	36 x 120	0.630	3.07566	18.90	8.5617
0.0178	0.45212	36 x 96	0.756	3.690792	18.15	8.22195
0.0178	0.45212	36 x 120	0.756	3.690792	22.68	10.27404
0.0178	0.45212	48 x 96	0.756	3.690792	24.19	10.95807
0.0178	0.45212	48 x 120	0.756	3.690792	30.24	13.69872
0.0235	0.5969	30 x 96	1.008	4.921056	20.16	9.13248
0.0235	0.5969	30 x 120	1.008	4.921056	25.20	11.4156
0.0235	0.5969	36 x 96	1.008	4.921056	24.19	10.95807
0.0235	0.5969	36 x 120	1.008	4.921056	30.24	13.69872
0.0235	0.5969	36 x 144	1.008	4.921056	36.29	16.43937
0.0235	0.5969	48 x 96	1.008	4.921056	32.26	14.61378
0.0235	0.5969	48 x 120	1.008	4.921056	40.32	18.26496
0.0235	0.5969	48 x 144	1.008	4.921056	48.39	21.92067
0.0291	0.73914	30 x 96	1.260	6.15132	25.20	11.4156
0.0291	0.73914	30 x 120	1.260	6.15132	31.50	14.2695
0.0291	0.73914	36 x 96	1.260	6.15132	30.24	13.69872
0.0291	0.73914	36 x 120	1.260	6.15132	37.80	17.1234
0.0291	0.73914	36 x 144	1.260	6.15132	45.37	20.55261
0.0291	0.73914	48 x 96	1.260	6.15132	40.32	18.26496
0.0291	0.73914	48 x 120	1.260	6.15132	50.41	22.83573
0.0291	0.73914	48 x 144	1.260	6.15132	60.49	27.40197
0.0355	0.9017	30 x 96	1.512	7.381584	30.24	13.69872
0.0355	0.9017	30 x 120	1.512	7.381584	37.80	17.1234
0.0355	0.9017	36 x 96	1.512	7.381584	36.29	16.43937

Weight Per Inconel 625 Sheets

Plate Thickness (mm)	Weight (kg/m)	kg/meter (width 1200mm)	kg/meter (width 1500mm)	kg/meter (width 1800mm)	kg/meter (width 2400mm)
3	23.55	28.3	35.3	42.4	56.5
4	31.4	37.7	47.1	56.5	75.4
5	39.25	47.1	58.9	70.7	94.2
6	47.1	56.5	70.7	84.8	113
8	62.8	75.4	94.2	113	150.7
10	78.5	94	118	141	188
12	94.2	113	141	170	226
16	125.6	151	188	226	301
20	157	188	236	283	377
22	172.7	207	259	311	415
25	196.25	236	294	353	471
28	219.8	264	330	396	528
32	251.2	301	377	452	603
36	282.6	339	424	509	678
40	314	377	471	565	754
45	353.25	424	530	636	848
50	392.5	471	589	707	942
55	431.75	518	648	777	1036
60	471	565	707	848	1130
65	510	612	765	918	1224
70	549.5	659	824	989	1319
75	588.75	707	883	1060	1413
80	628	754	942	1130	1507
90	706.5	848	1060	1272	1696
100	785	942	1178	1413	1884

Hot-rolled vs. cold-rolled Inconel 625 sheets

Both forms start from the same melt, but the finishing method changes how the sheet performs once it reaches a fabrication shop. Selecting between them usually comes down to whether the part needs heavy forming or tight dimensional control.

Feature	Hot-Rolled Sheet	Cold-Rolled Sheet
Process	Rolled at high temperature, then cooled and finished.	Pickled and then rolled again at room temperature for tighter control.
Surface finish	Rougher, less uniform surface.	Smoother, cleaner, more refined finish.
Dimensional accuracy	Good, but less precise than cold-rolled.	Higher thickness and width accuracy.
Mechanical strength	Adequate for many fabrications.	Slightly higher strength from cold work.
Formability	Easier for heavy forming and thicker parts.	Better for precision parts, though springback is higher.
Best use	Structural parts, heavy fabrication, and general industrial service.	Precision components, strip work, and finish-critical parts.

Why Choose Nandini Steel as Your Inconel 625 Sheet Supplier?

Nandini Steel supplies Inconel 625 sheets in hot-rolled and cold-rolled forms; mill test certificates and batch traceability are provided for every released coil and sheet. Our finishes include 2B, 2D, BA, mirror, brushed and hairline, and cut-to-size on request. Each order is tested for hardness, tensile strength, and corrosion resistance before dispatch and packed in wooden crates to ensure safe delivery across domestic and export shipments. As an Inconel 625 sheet manufacturer with ISO 9001:2015 certification, the focus stays on matching engineering specifications rather than pushing a fixed catalogue.

FAQs

How does Inconel 625 compare with Inconel 718?

Inconel 625 gets its strength from solid solution hardening and welds without post-weld heat treatment, while 718 relies on age hardening for higher strength at the cost of trickier fabrication. For parts needing frequent welding, 625 is usually the easier choice.

Are custom sizes and cut-to-size services available?

Yes, sheets are supplied cut to size on request, including profiling by laser, plasma, or oxy-propane flame cutting for specific part geometries.

What is the difference between Inconel 625 sheets and plates?

Sheets generally run thinner, from around 0.3 mm up to roughly 6 mm in cold-rolled form, while plates start above that and go up to 120 mm. The split affects the rolling method and typical use, with sheets suited to forming and plates to structural sections.

Which ASTM standard applies to Inconel 625 sheets?

The specification is controlled by ASTM B443 (ASME SB443), with the possibility of compliance with BS EN 10088-2 and EN 10028-7 or IS 6911 as appropriate to the project.

What thicknesses and surface finishes are available for Inconel 625 sheets?

The sheet thicknesses vary from 0.3 mm to 10 mm in both hot- and cold-rolled stock with surface finishes 2B, 2D, BA, mirror, brushed, or hairline.
