Order Premium Grade ASME SA387 Grade 11 Plate from Trusted Manufacturer in India. Chrome Moly SA387 Gr 11 Plates, Alloy Steel Grade 11 Plates, SA387 Grade 11 Pressure Vessel Plates Supplier in Mumbai.
Nandini Steel is a premium stockist and supplier of high-grade industrial steel plates. Being an ISO 9001:2015 certified organization, we provide the best product quality, customer satisfaction, and reliable supply chain management. Our extensive product includes the ASME SA387 Grade 11 Plate, a chromium-molybdenum alloy steel plate designed for high-temperature applications. It is used in pressure vessels and boilers because of its excellent heat and corrosion resistance. We manufacture it under a controlled rolling process with heat treatment. This plate is renowned for its performance and longevity even in severe conditions.
High-Temperature SA387 Gr 11 Steel Plate Exporter, ASTM A387 Grade 11 Class 1 & Class 2 Plates Stockist, SA387 Grade 11 Plate for Boilers and Pressure Vessels
Characteristics of ASME SA387 Grade 11 Plate:
- Better Thermal Resistance: While Grade 5 is effective for only medium temperatures, ASME SA387 Grade 11 Plate is effective even in severe heat conditions, and is thus more acceptable for use in pressure vessels and heat exchangers.
- Corrosion Protection is Superior: Grade 11 has a higher content of chromium and molybdenum therefore, it exhibits better resistance to oxidation, sulfidation and several other types of corrosion, especially in harsh environments.
- Higher Strength and Toughness: Grade 11 exhibits significantly better mechanical strength and impact resistance than Grade 5, thus providing reliability in highly stressed situations.
- Excellent Weldability & Fabrication: While both grades are weldable, ASME Sa387 Grade 11 Plate offers easier machinability and forming properties by making it more convenient for fabrication.
- Extended Service Life: It has a longer lifespan compared to Grade 5, reducing maintenance costs in industrial applications.
Compositions and Properties of ASME Sa387 Grade 11 Plate
The strength and durability of the ASME SA387 Grade 11 Plate are well-balanced composition. The chromium content is in the range of 1.00-1.50% which makes the plate resistant to oxidation, while the molybdenum content of 0.45-0.65% gives the plate excellent performance at high temperatures. The carbon content ranges from 0.05-0.17%, which helps to give outstanding tensile strength, whereas toughness is increased by manganese( 0.40-0.65%). These chemical properties make the plate highly reliable in extreme thermal and pressure conditions ensuring longevity and durability in demanding environments.
Applications of ASME Sa387 Grade 11 Plate
Our ASME Sa387 Grade 11 Plates are used in highly elevated temperature and pressure conditions. It is extensively used in the production of boilers, heat exchangers and pressure vessels, and hence it is essential in industries such as petrochemicals, power generation and refineries. Its superior mechanical properties also make it useful for offshore platforms and marine engineering, where resistance to extreme conditions is vital. Additionally, this plate is also used for structural purposes in thermal power plants and process piping systems because of its superior durability and reliability.
Packaging, Testing, and Delivery
We emphasize quality control through rigorous testing and safe packaging. Each UNS K11789 Plate is ultrasonically tested and mechanical properties are tested before despatch. We pack in with a proper wooden box, waterproof wrapping and clear labeling to prevent transit damage. Being a trusted ASTM A387 GR.11 CL.2 Steel Plates Supplier in India, we assure timely delivery in domestic and international markets.
Get the Best ASME SA387 Grade 11 Plate, Nandini Steel offers premium quality plates with unmatched service. Contact us today for bulk orders, price inquiries and expert assistance!
Other Types ASME Sa387 Grade 11 Plate
ASME Sa387 Grade 11 Chequered Plate
ASME Sa387 Grade 11 Polished Plate
ASME Sa387 Grade 11 Hot Rolled Plate
ASME Sa387 Grade 11 CR Plates
ASME Sa387 Grade 11 Clad Plate
ASME Sa387 Grade 11 Rolling Plate
ASME Sa387 Grade 11 Plate
ASME Sa387 Grade 11 2B Plates
ASME Sa387 Grade 11 Plate Specification
Specifications: ASTM A387 / ASME SA387
Dimensions: MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc
Size Range: 3.0–10.0 mm (hot rolled), 0.5-6.4 mm (cold rolled)
Thickness: 0.3 mm to 120 mm
Width: 1000mm, 1219mm, 1500mm, 1800mm, etc
Length: 2000mm,2440mm, 3000mm,5800mm, etc
| Element | Chemical Composition (%) | |
| SA387 Grade 11 | ||
| Carbon: | Heat Analysis: | 0.05 – 0.17 |
| Product Analysis: | 0.04 – 0.17 | |
| Manganese: | Heat Analysis: | 0.40 – 0.65 |
| Product Analysis: | 0.35 – 0.73 | |
| Phosphorus: | Heat Analysis: | 0.035 |
| Product Analysis: | 0.035 | |
| Sulphur (max): | Heat Analysis: | 0.035 |
| Product Analysis: | 0.035 | |
| Silicon: | Heat Analysis: | 0.50 – 0.80 |
| Product Analysis: | 0.44 – 0.86 | |
| Chromium: | Heat Analysis: | 1.00 – 1.50 |
| Product Analysis: | 0.94 – 1.56 | |
| Molybdenum: | Heat Analysis: | 0.45 – 0.65 |
| Product Analysis: | 0.45 – 0.70 |
| Tensile Strength | Yield Strength | Elongationin 200mm (%) | Elongation in 50mm (%) |
| 70-90 ksi, 485-620 MPa | 45 Ksi, 310 MPa | 18 | 22 |
| S | EN | ASTM/ASME | DIN |
| 621 B | ––– | SA387-11-2 | ––– |
ASME Sa387 Grade 11 Plate Thickness Chart
| Thickness | Width | Length |
|---|---|---|
| 8 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 60 | 1800 | 3400 |
| 6 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 4 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 12 | 2000 | 6000 |
| 10 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
Weight Per ASME Sa387 Grade 11 Plate
| Steel Plate Size (ft) | Pattern Height, in (mm) | Flat Plate Weight/Sheet (lbs) | Thickness (in. or AWG) | Checker Plate Weight/Sheet (lbs) |
| 4×8 | – | 33.06 | 22 gauge | – |
| – | 20.78 | 26 gauge | – | |
| – | 16.47 | 28 gauge | – | |
| – | 41.82 | 20 gauge | – | |
| 0.0197 (0.5) | 66.39 | 16 gauge | 79.19 | |
| – | 52.67 | 18 gauge | – | |
| 0.0315 (0.8) | 105.59 | 12 gauge | 125.11 | |
| 0.0256 (0.65) | 83.77 | 14 gauge | 97.14 | |
| 0.055 (1.40) | 163.35 | 1/8 | 192.15 | |
| 0.0256 (0.65) | 81.68 | 1/16 | 95.05 | |
| 0.060 (1.52) | 408.38 | 5/16 | 441.15 | |
| 326.71 | 1/4 | 359.47 | ||
| 245.03 | 3/16 | 277.80 | ||
| 571.74 | 7/16 | 604.50 | ||
| 490.06 | 3/8 | 522.83 | ||
| 735.09 | 9/16 | 767.86 | ||
| 653.41 | 1/2 | 686.18 | ||
| 898.44 | 11/16 | 931.21 | ||
| 816.77 | 5/8 | 849.53 | ||
| 1061.80 | 13/16 | 1094.56 | ||
| 980.12 | 3/4 | 1012.89 | ||
| 1306.83 | 1 | 1339.59 | ||
| 1143.47 | 7/8 | 1176.24 | ||
| 4×4 | – | 8.23 | 28 gauge | – |
| – | 10.39 | 26 gauge | – | |
| – | 16.53 | 22 gauge | – | |
| – | 20.91 | 20 gauge | – | |
| – | 26.33 | 18 gauge | – | |
| 0.0197 (0.5) | 33.19 | 16 gauge | 39.59 | |
| 0.0256 (0.65) | 41.88 | 14 gauge | 48.57 | |
| 0.0315 (0.8) | 52.80 | 12 gauge | 62.56 | |
| 0.0256 (0.65) | 40.84 | 1/16 | 47.53 | |
| 0.055 (1.40) | 81.68 | 1/8 | 96.08 | |
| 0.060 (1.52) | 122.51 | 3/16 | 138.90 | |
| 0.060 (1.52) | 163.35 | 1/4 | 179.74 | |
| 0.060 (1.52) | 245.03 | 3/8 | 261.41 | |
| 0.060 (1.52) | 326.71 | 1/2 | 343.09 | |
| 0.060 (1.52) | 490.06 | 3/4 | 506.44 | |
| 0.060 (1.52) | 653.41 | 1 | 669.80 | |
| 2×4 | – | 10.45 | 20 gauge | – |
| – | 5.19 | 26 gauge | – | |
| – | 4.12 | 28 gauge | – | |
| – | 8.27 | 22 gauge | – | |
| 0.0197 (0.5) | 16.60 | 16 gauge | 19.80 | |
| – | 13.17 | 18 gauge | – | |
| 0.0315 (0.8) | 26.40 | 12 gauge | 31.28 | |
| 0.0256 (0.65) | 20.94 | 14 gauge | 24.29 | |
| 0.055 (1.40) | 40.84 | 1/8 | 48.04 | |
| 0.0256 (0.65) | 20.42 | 1/16 | 23.76 | |
| 0.060 (1.52) | 81.68 | 1/4 | 89.87 | |
| 0.060 (1.52) | 61.26 | 3/16 | 69.45 | |
| 0.060 (1.52) | 163.35 | 1/2 | 171.55 | |
| 0.060 (1.52) | 122.51 | 3/8 | 130.71 | |
| 0.060 (1.52) | 326.71 | 1 | 334.90 | |
| 0.060 (1.52) | 245.03 | 3/4 | 253.22 | |
| 4×10 | – | 52.27 | 20 gauge | – |
| – | 25.97 | 26 gauge | – | |
| – | 20.58 | 28 gauge | – | |
| – | 65.83 | 18 gauge | – | |
| – | 41.33 | 22 gauge | – | |
| 0.0197 (0.5) | 82.98 | 16 gauge | 98.98 | |
| 0.0315 (0.8) | 131.99 | 12 gauge | 156.39 | |
| 0.055 (1.40) | 204.19 | 1/8 | 240.19 | |
| 0.0256 (0.65) | 104.71 | 14 gauge | 121.43 | |
| 0.060 (1.52) | 408.38 | 1/4 | 449.34 | |
| 0.0256 (0.65) | 102.10 | 1/16 | 118.82 | |
| 0.060 (1.52) | 816.77 | 1/2 | 857.73 | |
| 0.060 (1.52) | 306.29 | 3/16 | 347.25 | |
| 0.060 (1.52) | 1225.15 | 3/4 | 1266.11 | |
| 0.060 (1.52) | 612.57 | 3/8 | 653.53 | |
| 0.060 (1.52) | 1633.53 | 1 | 1674.49 | |
| 5×10 | – | 65.34 | 20 gauge | – |
| – | 32.47 | 26 gauge | – | |
| – | 25.73 | 28 gauge | – | |
| – | 51.66 | 22 gauge | – | |
| 0.0197 (0.5) | 103.73 | 16 gauge | 123.73 | |
| – | 82.29 | 18 gauge | – | |
| 0.0315 (0.8) | 164.99 | 12 gauge | 195.49 | |
| 0.0256 (0.65) | 130.89 | 14 gauge | 151.79 | |
| 0.055 (1.40) | 255.24 | 1/8 | 300.24 | |
| 0.0256 (0.65) | 127.62 | 1/16 | 148.52 | |
| 0.060 (1.52) | 510.48 | 1/4 | 561.68 | |
| 0.060 (1.52) | 382.86 | 3/16 | 434.06 | |
| 0.060 (1.52) | 1020.96 | 1/2 | 1072.16 | |
| 0.060 (1.52) | 765.72 | 3/8 | 816.92 | |
| 0.060 (1.52) | 2041.91 | 1 | 2093.11 | |
| 0.060 (1.52) | 1531.44 | 3/4 | 1582.64 |
