Now Available – Alloy 20 Plate, Carpenter 20 Plates, ASTM B463 Alloy 20 Plates, Nickel Alloy 20 Plates, Top Alloy 20 Plate Manufacturer & Supplier in Mumbai, India.
Corrosion-Resistant Alloy 20 Plate Exporter, Alloy 20 Sheet Stockist, UNS N08020 Plate Distributor, Werkstoff No. 2.4660 Alloy 20 Plates for Chemical Processing Industry, Heat Exchanger & Pharmaceutical Applications.
Key Features of Alloy 20 Plate
- Corrosion Resistance: Both alloys have better resistance to chemicals and acids but 904L is better in dealing with sulfuric acid whereas Alloy 20 Plate is resistant to both phosphoric and sulfuric acids and hence more versatile for different industries.
- Mechanical Properties: 904L possesses improved low-temperature toughness, but Alloy 20 Plate exhibits good resistance to stress corrosion cracking, particularly in highly acidic conditions.
- Cost-Effective: Alloy 20 Plate is comparatively affordable than 904L without compromising on the integral characteristics like durability and resistance to corrosion, thus proving to be a cost-effective option for most applications.
Compositions and Properties of Alloy 20 Plate
The chemical composition of Alloy 20 Plate is specially designed to achieve maximum strength and resistance in severe environments.Nickel (Ni) – 32% is the main component that offers resistance to chloride stress corrosion cracking, whereas Chromium (Cr) – 20% increases its oxidation resistance. The inclusion of Molybdenum (Mo) – 3% provides better resistance to pitting and crevice corrosion, making Alloy 20 Plate suitable for environments that are exposed to aggressive chemicals such as sulfuric acid.
The high Iron content balances the alloy’s cost while maintaining its mechanical properties and corrosion resistance. Its regulated Carbon content makes the alloy stable at high temperatures without being affected by carbide precipitation. The balanced content gives Alloy 20 Plate higher strength and endurance, guaranteeing long lasting service life in severe applications like chemical processing, food processing and pharmaceutical manufacturing.
Packaging, Testing & Delivery
We make sure that all our products, such as Alloy 20 Plate are packed carefully to prevent damage during shipping. Our plates are covered with moisture-resistant material and tied up in custom wood crates to preserve their integrity and quality.Every Alloy UNS N08020 Plate goes through proper testing to verify that it complies with international standards. Our testing consists of chemical composition, mechanical testing and corrosion resistance testing.We give detailed certificates and reports, including our ISO 9001:2015, which assures you of the best quality management practices throughout our processes. We supply our ASTM B463 Alloy 20 Quarto Plates and other products within deadlines and in pristine condition.
Don’t settle for less when it comes to material quality. Choose Nandini Steel for your Alloy 20 Plate needs, where we combine exceptional performance with industry-leading expertise. Whether you need ASTM B463 UNS N08020 Alloy 20 Plates or Alloy 20 Chequered Plates, we provide reliable products designed to meet the most stringent requirements. Contact us today to get a quote or to discuss your project needs with our expert team.
Let Nandini Steel be your trusted partner for high-quality Alloy 20 Plates or 2.4660 Strip.
Other Types of Alloy 20 Plates
Alloy 20 Chequered Plate
Alloy 20 Polished Plate
Alloy 20 Hot Rolled Plate
Alloy 20 CR Plates
Alloy 20 Clad Plate
Alloy 20 Rolling Plate
Matt PVC Alloy 20 Plate
2B Alloy 20 Plates
Alloy 20 Plates Specification
Grade: B463 UNS N08020, Incoloy Alloy 20, Carpenter 20, 20Cb-3, CARPENTER alloy 20Cb-3
Thickness : 7 gauge to 28 gauge or 3.664mm to .321mm
Width Range : 30″ to 240″
Length Range : Up to144″ Non-Standard or Longer Lengths Available Upon Request
Processing : Shearing to Custom Sizes
Surface: 2B, No.3, No.4, HL, BA, 8K
| Nickel | Chromium | Carbon | Copper | Molybdenum | Manganese | Silicon | Columbium | Iron |
| 32.5-35% | 19-21% | 0.06% maximum | 3-4% | 2-3% | 2% maximum | 1% maximum | 1% maximum | 31-44% (balance) |
| Tensile Strength | Yield Strength | Elongation | Hardness MAX |
| 80 ksi | 35ksi | 30% | 217 |
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Alloy 20 | N08020 | 2.4660 | Z2NCUD31-20AZ | NiCr20CuMo | – | – | – |
Alloy 20 Plate Thickness Chart
| Metric Thickness (mm) | Imperial Thickness (inches) | Typical Tolerance |
| 3.0 mm | 0.118 in | ±0.25 mm |
| 4.0 mm | 0.157 in | ±0.25 mm |
| 5.0 mm | 0.197 in | ±0.25 mm |
| 6.0 mm | 0.236 in | ±0.30 mm |
| 8.0 mm | 0.315 in | ±0.30 mm |
| 10.0 mm | 0.394 in | ±0.30 mm |
| 12.0 mm | 0.472 in | ±0.35 mm |
| 16.0 mm | 0.630 in | ±0.40 mm |
| 20.0 mm | 0.787 in | ±0.50 mm |
| 25.0 mm | 0.984 in | ±0.60 mm |
| 30.0 mm | 1.181 in | ±0.70 mm |
| 40.0 mm | 1.575 in | ±0.80 mm |
| 50.0 mm | 1.969 in | ±1.00 mm |
Weight Per Alloy 20 Plate
| Thickness (mm) | Plate Size (m x m) | Weight per Plate (kg) |
| 3 mm | 1m x 2m | 48.6 kg |
| 4 mm | 1m x 2m | 64.8 kg |
| 5 mm | 1m x 2m | 81 kg |
| 6 mm | 1m x 2m | 97.2 kg |
| 8 mm | 1m x 2m | 129.6 kg |
| 10 mm | 1m x 2m | 162 kg |
| 12 mm | 1m x 2m | 194.4 kg |
| 16 mm | 1m x 2m | 259.2 kg |
| 20 mm | 1m x 2m | 324 kg |
| 25 mm | 1m x 2m | 405 kg |
