Shop Our Large Selection Of Hastelloy C276 Coils, Get Custom Cut-To-Size Options With Various Widths Available
Nandini Steel is a trusted name in the metal industry, offering high-quality products with ISO 9001:2015 certification. We specialize in manufacturing and supplying Hastelloy C276 Coil, a corrosion-resistant alloy coil available in various thicknesses, sizes, and lengths to meet diverse industrial needs. These coils are widely used due to their exceptional resistance to oxidation, pitting, and stress corrosion cracking. Manufactured through precision processes such as cold rolling and annealing, our coils comply with ASTM, ASME, DIN, JIS, and EN standards, ensuring superior quality and reliability.
Top Hastelloy C276 Coil Manufacturer and Supplier in Mumbai – Available in Various Thicknesses, Widths & Finishes at the Best Market Price
Key Features of Hastelloy C276 Coils
- Exceptional Corrosion Resistance: Hastelloy UNS N10276 Coils provide superior resistance to oxidizing and reducing conditions, besting other nickel-based alloys.
- High Temperature Stability: ASME SB575 Hastelloy C-276 does not lose strength and corrosion resistance, when used in high-heat conditions as opposed to Hastelloy C22.
- Increased Pitting Resistance: Hastelloy C276 Coil contains more molybdenum than Hastelloy C22, resulting in greater pitting, and crevice corrosion protection.
- Better Weldability: Although Hastelloy C22 requires post-weld heat treatment to ensure corrosion resistance hastelloy Alloy C276 Coils can be welded without post weld heat treatments.
- Better Performance in Harsh Environments: Alloy C-276 Coil is preferred over Hastelloy C22 for chemical processing, marine applications, and power plants due to its outstanding durability in aggressive media.
- Greater Versatility: Hastelloy C276 Coiled Tubing is more versatile than C22 hastelloy, making it the go-to choice for industries requiring high-performance materials.
Composition and Properties of Hastelloy C276 Coil
The better performance of hastelloy C276 Coil is attributed to its special chemical composition. With 57% Nickel, the alloy has outstanding corrosion resistance especially in acidic, and chloride environments. The addition of 16% Molybdenum increases its strength and pitting resistance, while 15% Chromium increases oxidation resistance. In addition, 5% Iron and traces of Tungsten also add to its hardness and durability. These combined factors make this alloy one of the most dependable options for extreme industrial use.
Uses of Hastelloy C276 Coil
Our hastelloy C276 coil finds its extensive usage in various sectors based on its superior characteristics. It is utilized in heat exchangers, reactors, and corrosive chemical piping systems in the chemical processing industry. The aerospace and marine industries utilize its capability for high seawater corrosion resistance. It is well suited for flue gas scrubbers, ducting and heat recovery units in the power generation business. Additionally, Hastelloy C276 Coiled Tubing is extensively used in pharmaceutical and food processing applications where hygiene and corrosion resistance are critical.
Packaging, Testing & Delivery
As a hastelloy Alloy C276 Coils Stockist, we ensure high-quality packaging and follow stringent quality checks, including tensile testing, ultrasonic testing, and PMI (Positive Material Identification). Each coil is packed safely in wooden crates, steel-strapped bundles, or custom-made packaging to withstand safe handling during transit. Our logistics ensure timely and safe delivery according to international shipping standards. We also provide mill test certificates, third-party inspection, and compliance certificates for end-to-end quality assurance.
Seeking best-quality Hastelloy UNS N10276 Coils? We are your go-to supplier, providing the best products at competitive prices. Call us now for a quote or expert advice on selecting the appropriate coil for your project!
Other Types Hastelloy C276 Coils
Hastelloy C276 Slit Coils
Hastelloy C276 B2 Coils
Hastelloy C276 Strip Coils
Hastelloy C276 Rolled Coil
Hastelloy C276 Coils Specification
Sheet Specifications: ASTM B575 / ASME SB575
Standard: ASTM, ASME and API
Size: 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm,
Thickness Range: 1.0mm – 200mm
Range: 5 mm To 50 mm thick in 1000 mm TO 1250 mm width & 2500 mm Length
Production: Hot-Rolled (HR) / Cold-Rolled (CR)
Form: Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Grade: Hastelloy C276 Sheets, Plates & Coils UNS (N10276), DIN (2.4819)
| Grade | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr | W | V |
| Hastelloy 276 | Balance | 0.01 max | 15–17 | 1.0 max | 0.08 max | 4–7 | 0.04 max | 0.03 max | 2.5 max | 14.5–16.5 | 3–4.5 | 0.35 max |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy 276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | OR | GOST |
| Hastelloy 276 | N10276 | 2.4819 | – | NiMo16Cr15W | NW 0276 | ЭП760 | ХН65МВУ |
Hastelloy C276 Coils Thickness Chart
| Thickness | Thickness | Size Range | Surface Area per Unit weight | Approx Weight per Sheet | ||
| inches | mm | lbs/ft² | kg/m² | lbs | kg | |
| 0.015 | 0.381 | 36 x 96 | 0.630 | 3.07566 | 15.12 | 6.84936 |
| 0.015 | 0.381 | 36 x 120 | 0.630 | 3.07566 | 18.90 | 8.5617 |
| 0.0178 | 0.45212 | 36 x 96 | 0.756 | 3.690792 | 18.15 | 8.22195 |
| 0.0178 | 0.45212 | 36 x 120 | 0.756 | 3.690792 | 22.68 | 10.27404 |
| 0.0178 | 0.45212 | 48 x 96 | 0.756 | 3.690792 | 24.19 | 10.95807 |
| 0.0178 | 0.45212 | 48 x 120 | 0.756 | 3.690792 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 30 x 96 | 1.008 | 4.921056 | 20.16 | 9.13248 |
| 0.0235 | 0.5969 | 30 x 120 | 1.008 | 4.921056 | 25.20 | 11.4156 |
| 0.0235 | 0.5969 | 36 x 96 | 1.008 | 4.921056 | 24.19 | 10.95807 |
| 0.0235 | 0.5969 | 36 x 120 | 1.008 | 4.921056 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 36 x 144 | 1.008 | 4.921056 | 36.29 | 16.43937 |
| 0.0235 | 0.5969 | 48 x 96 | 1.008 | 4.921056 | 32.26 | 14.61378 |
| 0.0235 | 0.5969 | 48 x 120 | 1.008 | 4.921056 | 40.32 | 18.26496 |
| 0.0235 | 0.5969 | 48 x 144 | 1.008 | 4.921056 | 48.39 | 21.92067 |
| 0.0291 | 0.73914 | 30 x 96 | 1.260 | 6.15132 | 25.20 | 11.4156 |
| 0.0291 | 0.73914 | 30 x 120 | 1.260 | 6.15132 | 31.50 | 14.2695 |
| 0.0291 | 0.73914 | 36 x 96 | 1.260 | 6.15132 | 30.24 | 13.69872 |
| 0.0291 | 0.73914 | 36 x 120 | 1.260 | 6.15132 | 37.80 | 17.1234 |
| 0.0291 | 0.73914 | 36 x 144 | 1.260 | 6.15132 | 45.37 | 20.55261 |
| 0.0291 | 0.73914 | 48 x 96 | 1.260 | 6.15132 | 40.32 | 18.26496 |
| 0.0291 | 0.73914 | 48 x 120 | 1.260 | 6.15132 | 50.41 | 22.83573 |
| 0.0291 | 0.73914 | 48 x 144 | 1.260 | 6.15132 | 60.49 | 27.40197 |
| 0.0355 | 0.9017 | 30 x 96 | 1.512 | 7.381584 | 30.24 | 13.69872 |
| 0.0355 | 0.9017 | 30 x 120 | 1.512 | 7.381584 | 37.80 | 17.1234 |
| 0.0355 | 0.9017 | 36 x 96 | 1.512 | 7.381584 | 36.29 | 16.43937 |
Weight Per Hastelloy C276 Coils
| Thickness | Coil Weight per Unit Area | Density |
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
