Inconel 825 Coils, Alloy 825 Coils, UNS N08825 Coils, WNR 2.4858 Coils, Nickel Alloy 825 Coil Supplier, ASTM B424 Inconel 825 Coil, Corrosion Resistant Inconel 825 Coils, High Strength Inconel 825 Coil
Inconel 825 Coil is a high-performance nickel-iron-chromium alloy for use in extreme environments. Nandini Steel is a reliable Inconel 825 Coils Supplier in Mumbai, India, dedicated to providing high-quality Inconel 825 Coils according to international standards. Being an ISO 9001:2015 accredited company, we guarantee that every product is developed with utmost precision.Our Coils of Incoloy 825 are processed following ASTM, ASME, DIN, JIS, and EN specifications and have different thickness, size, and length options for fulfilling particular customers’ needs.Our coils are carefully designed with strict specifications in mind and receive rigorous quality inspections prior to release.
Cold Rolled Inconel 825 Coil, Hot Rolled Inconel 825 Coil, Inconel 825 Coil for Chemical Processing, Inconel 825 Coil Exporter, Inconel 825 Coil Stockist, Inconel 825 Coil Price, Buy Inconel 825 Coils Online.
Key Features of Inconel 825 Coil
- Corrosion Resistance: Inconel 825 Coil possesses excellent resistance to a broad array of corrosive environments, including sulfuric and phosphoric acid, seawater and most other industrial chemicals.
- High Strength: The alloy exhibits high tensile and yield strength even at higher temperatures, thereby maintaining its strength and dependability in hostile conditions.
- Outstanding Fabricability: In contrast with other high-performing alloys Incoloy N08825 Coils have good weldability and can easily be shaped to complex geometries without sacrificing performance.
- Improved Thermal Stability: Inconel 825 Coil shows good performance between cryogenic temperatures and high temperatures, making it ideal for diverse industrial applications.
- Comparison with Inconel 600: In contrast to Inconel 600, which has greater susceptibility to stress corrosion cracking, Inconel 825 Coils possess better resistance to stress corrosion, pitting, as well as crevice corrosion, particularly in chloride-bearing conditions.
Compositions and Properties of Inconel 825 Coil
The unique composition of Inconel 825 Coil provides it with exceptional properties that set it apart from other alloys.The alloy is composed of approximately 38-46% nickel, 19-23% chromium, 2.5-3.5% molybdenum, and 1.5-3% copper. The presence of these elements enables Incoloy 825 Coils to offer superior corrosion resistance, oxidation, and other environmental degradation. The presence of copper within the alloy gives it a better resistance to sulfuric acid and other corrosive chemicals, thus recommending it for application in chemical processing industries.The high concentration of chromium increases its oxidation resistance, while its nickel content enables it to withstand strength and ductility even in high temperatures.This combination makes Incoloy 2.4858 Coils reliable across a broad series of harsh applications.
Applications of Inconel 825 Coil
The nature of Inconel 825 Coil makes it fit for various applications in different industries. Its remarkable resistance to heat, corrosion and chemical decay makes it a good fit for chemical processing, pollution control apparatuses and nuclear waste treatment facilities. UNS N08825 Coils find extensive application in the production of heat exchangers, reactors and flue gas desulfurization units. The alloy’s resistance to pitting and stress corrosion cracking makes it particularly useful in marine and offshore applications. Incoloy N08825 Coils are used in aerospace parts, pressure vessels, as well as in the production of components used in the oil and gas industries, where they are exposed to high temperatures and hostile conditions.
Packaging, Testing & Delivery
We take utmost care to pack Incoloy 825 Coils so that there is no damage during shipping. Every coil is thoroughly tested for its mechanical properties, chemical composition and dimensional accuracy. We maintain stringent quality control measures to ensure that our products are of the highest quality in terms of performance and reliability. The testing involves tensile strength, hardness and corrosion resistance testing, which are conducted by our experienced team of professionals.We also provide personalized packaging and fast delivery services, so that our customers get their products delivered on time, without any compromise on quality.
Ready to feel the unmatched performance and strength of Inconel 825 Coil? Whether you require Incoloy 825 Coils Supplier services, customized sizes or specified thicknesses we have you covered. Our Alloy 825 Coils are manufactured to provide the best industry standards, ensuring the best performance in even the most extreme applications. Contact us now for a quote or more information on how our products can meet your needs.
Other Types Inconel 825 Coils
Inconel 825 Hot Rolled Coils
Inconel 825 Cold Rolled Coils
Inconel 825 Polished Coils
Inconel 825 Matt PVC Coils
Inconel 825 Slitting Coils
Inconel Steel 825 Strip Coils
Inconel 825 HR Coils
2B Inconel 825 Coils
Inconel 825 Coils Specification
Dimensions: MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc
Size Range: Cold Rolled 0.5-6.4 mm, Hot Rolled 3.0–10.0 mm
Thickness: 0.3 mm to 120 mm.
Width: 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc.
Length: 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Tolerances (width / thickness): EN 10258/ DIN 59381 EN 10151 EN 10088
Form: Sheet, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, soft annealed, descaled, sheared, annealed
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 825 | 0.05 max | 1.00 max | 0.05 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Inconel 825 | 2.4858 | N08825 | NCF 825 | NA 16 | ЭП703 | NFE30C20DUM | NiCr21Mo | XH38BT |
Inconel 825 Coil Thickness Chart
| Strip Thickness | Width | |||
| 320≤W＜600 | W＜320 | |||
| T1 | T2 | T3 | T4 | |
| T＜0.05 mm | 0.004 | 0.003 | 0.003 | 0.002 |
| 0.05≤T＜0.07 | 0.005 | 0.004 | 0.004 | 0.003 |
| 0.07≤T＜0.08 | 0.006 | 0.005 | 0.005 | 0.003 |
| 0.08≤T＜0.10 | 0.007 | 0.005 | 0.005 | 0.003 |
| 0.10≤T＜0.13 | 0.009 | 0.007 | 0.006 | 0.004 |
| 0.13≤T＜0.15 | 0.010 | 0.008 | 0.007 | 0.004 |
| 0.15≤T＜0.20 | 0.011 | 0.009 | 0.008 | 0.004 |
| 0.20≤T＜0.25 | 0.013 | 0.010 | 0.008 | 0.005 |
| 0.25≤T＜0.30 | 0.015 | 0.011 | 0.009 | 0.005 |
| 0.30≤T＜0.35 | 0.016 | 0.012 | 0.010 | 0.005 |
| 0.35≤T＜0.40 | 0.018 | 0.012 | 0.010 | 0.005 |
| 0.40≤T＜0.50 | 0.020 | 0.015 | 0.012 | 0.005 |
| 0.50≤T＜0.60 | 0.022 | 0.018 | 0.013 | 0.005 |
| 0.60≤T＜0.70 | 0.024 | 0.020 | 0.015 | 0.005 |
| 0.70≤T＜0.80 | 0.026 | 0.022 | 0.017 | 0.005 |
| 0.80≤T＜0.90 | 0.028 | 0.024 | 0.018 | 0.006 |
| 0.90≤T＜1.00 | 0.032 | 0.027 | 0.020 | 0.008 |
| 1.00≤T＜1.20 | 0.035 | 0.030 | 0.022 | 0.008 |
| 1.20≤T＜1.40 | 0.040 | 0.035 | 0.025 | 0.010 |
| 1.40≤T＜1.60 | 0.045 | 0.040 | 0.030 | 0.020 |
Weight Per Inconel 825 Coils
| Thick. on base (millimeter) | Unit Wght / Coil (kilogram) |
| 3000 x1000 x3.0 | 78.0 |
| 3000 x1250 x4.5 | 143.0 |
| 3000 x1250 x6.0 | 180.0 |
| 3000 x1250 x8.0 | 210.0 |
