Inconel 800h coil is a high-performance alloy mainly employed in applications requiring exceptional resistance to carburization and oxidation at elevated temperatures. The Inconel family is known for its resilience under harsh conditions and superior strength. Nandini Steel, a trusted Inconel 800h coil supplier based in Mumbai, delivers this extraordinary material to industries all over the globe.Since we are ISO 9001:2015 certified, we adhere to the highest quality and precision standards in the manufacturing process.The Inconel 800h coil is produced in compliance with ASTM, ASME, DIN, JIS, and EN specifications for uniformity and performance. The alloy is supplied in different thicknesses, sizes and lengths catering to individual customer requirements.
Incoloy 800H Circle, Incoloy 800H Coils, Trusted 800H Coils Exporter, Incoloy 800H Cold Rolled Coils, ASTM B 409 Incoloy 800H Shim Coils,
Key Features of Inconel 800H Coil
- Higher Strength: In comparison to other alloys such as Alloy 600, Inconel 800h provides higher strength and resistance to oxidation at elevated temperatures, which makes it suitable for high-temperature environments.
- Good Corrosion Resistance: In contrast to Inconel 600 which exhibits deficiencies in carburizing conditions, Inconel 800h possesses good resistance to oxidation and carburization at high temperatures.
- Long-Term Stability: The improved creep-resistance of Inconel 800h Coil makes it better for long-term exposure to high-temperature applications.
- Formability:It has good workability and it is simpler to shape than some of its more alloyed relatives.
- Weldability: The Inconel 800h Coil can be welded without loss of structure, as opposed to other alloys that tend to weaken at weld joints.
Compositions and Properties of Inconel 800H Coil
Inconel 800h Coil has approximately 30-35% nickel and 19-23% chromium with excellent resistance to carburization and oxidation in high-temperature conditions. The iron content (up to 49%) in the composition provides the alloy with its strength, while the carbon content (0.05%-0.10%) improves the creep resistance, making it suitable for application in power generation and heat exchangers.This special combination renders the alloy perfect for use in conditions where other materials would collapse because of corrosion or heat deterioration.Its controlled carbon content combined with nickel and chromium makes it highly thermally stable, a feature that distinguishes it.
Applications of Inconel 800H Coil
The corrosion-resistant and high-temperature characteristics of Inconel 800h Coil make it a highly suitable option for numerous industrial uses. It finds widespread application in the power generation sector, specifically in furnace components, heat exchangers and reactors. Inconel 800h Coil is also commonly applied in chemical processing sectors, especially where heat, corrosive and pressure conditions exist. Some other common uses include gas turbines, steam generators and industrial furnaces. The alloy is also used in the food processing sector because of its tolerance to oxidation as well as carburization, which offers a durable solution to components that are subjected to high temperatures.
Packaging, Testing & Delivery
We make sure that all Inconel 800h coils are packed with great care so that there is no transit damage. Our packing process is such that the product reaches the destination in perfect condition. We perform stringent testing before delivery to ensure dimensional accuracy, surface condition, and conformance to international standards.Our coils are subjected to different tests, such as mechanical testing, hardness testing, and chemical composition analysis, to ensure they meet or surpass customer expectations. After testing we make sure to deliver them to your doorstep quickly, ensuring that your projects are not delayed.
We are your trusted Inconel 800h Coil supplier in Mumbai you can rely on for superior quality and on-time delivery. Contact us today for a quote and learn more about how our products can meet your high-performance alloy needs!
Other Types Inconel 800H Coils
Inconel 800H Hot Rolled Coils
Inconel 800H Cold Rolled Coils
Inconel 800H Polished Coils
Inconel 800H Matt PVC Coils
Inconel 800H Slitting Coils
Inconel Steel 800H Strip Coils
Inconel 800H HR Coils
2B Inconel 800H Coils
Inconel 800H Coils Specification
Dimensions: MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc
Size Range: Cold Rolled 0.5-6.4 mm, Hot Rolled 3.0–10.0 mm
Thickness: 0.3 mm to 120 mm.
Width: 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc.
Length: 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Tolerances (width / thickness): EN 10258/ DIN 59381 EN 10151 EN 10088
Form: Sheet, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, soft annealed, descaled, sheared, annealed
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Incoloy 800H | 1.4958 / 1.4876 | N08810 | NCF 800H | NA 15(H) | ЭИ670 | Z8NC33-21 | X5NiCrAlTi31-20 | XH32T |
Inconel 800H Coil Thickness Chart
| Strip Thickness | Width | |||
| 320≤W＜600 | W＜320 | |||
| T1 | T2 | T3 | T4 | |
| T＜0.05 mm | 0.004 | 0.003 | 0.003 | 0.002 |
| 0.05≤T＜0.07 | 0.005 | 0.004 | 0.004 | 0.003 |
| 0.07≤T＜0.08 | 0.006 | 0.005 | 0.005 | 0.003 |
| 0.08≤T＜0.10 | 0.007 | 0.005 | 0.005 | 0.003 |
| 0.10≤T＜0.13 | 0.009 | 0.007 | 0.006 | 0.004 |
| 0.13≤T＜0.15 | 0.010 | 0.008 | 0.007 | 0.004 |
| 0.15≤T＜0.20 | 0.011 | 0.009 | 0.008 | 0.004 |
| 0.20≤T＜0.25 | 0.013 | 0.010 | 0.008 | 0.005 |
| 0.25≤T＜0.30 | 0.015 | 0.011 | 0.009 | 0.005 |
| 0.30≤T＜0.35 | 0.016 | 0.012 | 0.010 | 0.005 |
| 0.35≤T＜0.40 | 0.018 | 0.012 | 0.010 | 0.005 |
| 0.40≤T＜0.50 | 0.020 | 0.015 | 0.012 | 0.005 |
| 0.50≤T＜0.60 | 0.022 | 0.018 | 0.013 | 0.005 |
| 0.60≤T＜0.70 | 0.024 | 0.020 | 0.015 | 0.005 |
| 0.70≤T＜0.80 | 0.026 | 0.022 | 0.017 | 0.005 |
| 0.80≤T＜0.90 | 0.028 | 0.024 | 0.018 | 0.006 |
| 0.90≤T＜1.00 | 0.032 | 0.027 | 0.020 | 0.008 |
| 1.00≤T＜1.20 | 0.035 | 0.030 | 0.022 | 0.008 |
| 1.20≤T＜1.40 | 0.040 | 0.035 | 0.025 | 0.010 |
| 1.40≤T＜1.60 | 0.045 | 0.040 | 0.030 | 0.020 |
Weight Per Inconel 800H Coils
| Thick. on base (millimeter) | Unit Wght / Coil (kilogram) |
| 3000 x1000 x3.0 | 78.0 |
| 3000 x1250 x4.5 | 143.0 |
| 3000 x1250 x6.0 | 180.0 |
| 3000 x1250 x8.0 | 210.0 |
