Inconel 625 Coils, Alloy 625 Coils, Cold Rolled Inconel 625 Coil, WNR 2.4856 Coils, Inconel 625 Coil Stockist, ASTM B443 Inconel 625 Coil, Inconel 625 Coil Exporter, Nickel Alloy 625 Coil Supplier
At Nandini Steel, we take pride in being one of the leading Inconel 625 Coil Suppliers in the industry. With our commitment to delivering top-notch products, we hold the ISO 9001:2015 certification, which reflects our dedication to quality management systems. We deal in high-performance materials such as Inconel 625 Coils, which is a nickel-chromium alloy that provides excellent resistance to carburization, oxidation, and general corrosion. It is used in numerous industries where superior strength and corrosion resistance are needed. These coils are produced through high-tech manufacturing methods, including vacuum induction melting, to provide the best quality. The production process is controlled to meet the most stringent standards such as ASTM, ASME, DIN, JIS and EN standards.
Buy Inconel 625 Coils Online, High Strength Inconel 625 Coil, UNS N06625 Coils, Corrosion Resistant Inconel 625 Coil, Hot Rolled Inconel 625 Coil, Inconel 625 Coil for Offshore Applications, Inconel 625 Coil Price.
Key Features of Inconel 625 Coil
- Corrosion Resistance: Inconel 625 Coil is corrosion resistant and can be utilized in harsh conditions such as high-temperature, and chemically aggressive environments.
- Strength at High Temperatures: In contrast to other alloys like Inconel 718, Inconel 625 Coil boasts better high-temperature performance, and is better suited for operating in high heat and pressure conditions.
- Good Weldability: Nickel alloy 625 strip coil possesses very good weldability and welding stress cracking resistance compared to alloys like Inconel 600 that tend to crack more easily.
- Outstanding Fatigue and Thermal-fatigue Strength: Compared to alloys like Inconel 600, Inconel 625 Coil exhibits better fatigue and thermal-fatigue strength, which is critical in harsh service conditions.
- Superb Fabricability: Inconel 625 Coil offers great formability and can be easily processed into a variety of shapes without losing its mechanical properties, making it a preferred choice for complex designs.
Composition and Properties of Inconel 625 Coil
Our inconel 625 coil consists of nickel (58% minimum), combined with chromium (20-23%), molybdenum (8-10%), and niobium (3.15-4.15%), making it extremely resistant to corrosion and oxidation. Nickel content in the alloy provides it with stress-corrosion cracking as well as oxidation resistance in high-temperature conditions. Chromium increases its corrosion and oxidation resistance, and molybdenum and niobium provide superior pitting and crevice corrosion resistance. Inconel 625 coil’s distinct composition enables it to excel in the aerospace, marine and chemical processing industries, providing toughness and long service life even in harsh conditions.
Applications of Inconel 625 Coil
Inconel 625 Coil is widely used in industries where exceptional resistance to heat, corrosion, and wear is required. In aerospace, it is used in components like turbine blades, seals, and exhaust systems. The chemical processing industry uses Nickel Alloy 625 Strip Coil in reactors, heat exchangers, and pumps because of its resistance to corrosive chemicals. Marine industries also rely on Alloy 625, UNS N06625, & W.Nr. 2.4856 Coils for constructing seawater piping systems, where exposure to saltwater can cause quick corrosion. It is also found in pollution control equipment, nuclear reactors, and other high-stress environments where reliability and strength are crucial.
Packaging, Testing & Delivery
We ensure that every inconel 625 coil is handled with the utmost care, from manufacturing to delivery. Our coils are available in various thicknesses, sizes, and lengths, tailored to meet the specific needs of our clients. We pack the coils safely to keep them in the best condition. We perform rigorous quality tests on each batch, involving tensile, hardness, and corrosion resistance tests, to match the industry standards. Our seamless delivery process ensures timely shipment and we have our customer support ready to help you with your needs.
Whether you are in aerospace, chemical processing, or marine industries, we are your reliable partner for Inconel 625 Coils. Get in touch with us today to obtain the best Inconel 625 Coil for your needs and explore our range of high-performance alloys tailored to your requirements.
Other Types Inconel 625 Coils
Inconel 625 Hot Rolled Coils
Inconel 625 Cold Rolled Coils
Inconel 625 Polished Coils
Inconel 625 Matt PVC Coils
Inconel 625 Slitting Coils
Inconel Steel 625 Strip Coils
Inconel 625 HR Coils
2B Inconel 625 Coils
Inconel 625 Coils Specification
Specifications: ASTM B409 / ASME SB409
Dimensions: MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc
Size Range: Cold Rolled 0.5-6.4 mm, Hot Rolled 3.0–10.0 mm
Thickness: 0.3 mm to 120 mm.
Width: 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc.
Length: 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Tolerances (width / thickness): EN 10258/ DIN 59381 EN 10151 EN 10088
Form: Sheet, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, soft annealed, descaled, sheared, annealed
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
Inconel 625 Coil Thickness Chart
| Strip Thickness | Width | |||
| 320≤W＜600 | W＜320 | |||
| T1 | T2 | T3 | T4 | |
| T＜0.05 mm | 0.004 | 0.003 | 0.003 | 0.002 |
| 0.05≤T＜0.07 | 0.005 | 0.004 | 0.004 | 0.003 |
| 0.07≤T＜0.08 | 0.006 | 0.005 | 0.005 | 0.003 |
| 0.08≤T＜0.10 | 0.007 | 0.005 | 0.005 | 0.003 |
| 0.10≤T＜0.13 | 0.009 | 0.007 | 0.006 | 0.004 |
| 0.13≤T＜0.15 | 0.010 | 0.008 | 0.007 | 0.004 |
| 0.15≤T＜0.20 | 0.011 | 0.009 | 0.008 | 0.004 |
| 0.20≤T＜0.25 | 0.013 | 0.010 | 0.008 | 0.005 |
| 0.25≤T＜0.30 | 0.015 | 0.011 | 0.009 | 0.005 |
| 0.30≤T＜0.35 | 0.016 | 0.012 | 0.010 | 0.005 |
| 0.35≤T＜0.40 | 0.018 | 0.012 | 0.010 | 0.005 |
| 0.40≤T＜0.50 | 0.020 | 0.015 | 0.012 | 0.005 |
| 0.50≤T＜0.60 | 0.022 | 0.018 | 0.013 | 0.005 |
| 0.60≤T＜0.70 | 0.024 | 0.020 | 0.015 | 0.005 |
| 0.70≤T＜0.80 | 0.026 | 0.022 | 0.017 | 0.005 |
| 0.80≤T＜0.90 | 0.028 | 0.024 | 0.018 | 0.006 |
| 0.90≤T＜1.00 | 0.032 | 0.027 | 0.020 | 0.008 |
| 1.00≤T＜1.20 | 0.035 | 0.030 | 0.022 | 0.008 |
| 1.20≤T＜1.40 | 0.040 | 0.035 | 0.025 | 0.010 |
| 1.40≤T＜1.60 | 0.045 | 0.040 | 0.030 | 0.020 |
Weight Per Inconel 625 Coils
| Thick. on base (millimeter) | Unit Wght / Coil (kilogram) |
| 3000 x1000 x3.0 | 78.0 |
| 3000 x1250 x4.5 | 143.0 |
| 3000 x1250 x6.0 | 180.0 |
| 3000 x1250 x8.0 | 210.0 |
