Inconel 601 Coils, Alloy 601 Coils, UNS N06601 Coils, WNR 2.4851 Coils, ASTM B168 Inconel 601 Coil, High Temperature Inconel 601 Coil, Inconel 601 Coil Exporter, Corrosion Resistant Inconel 601 Coils,
Inconel 601 Coil is a high-strength nickel-chromium-iron alloy coil that has high-temperature oxidation and corrosion resistance. These coils find widespread application in conditions requiring strength and durability at high temperatures. Nandini Steel is a reliable Inconel 601 Coils Supplier with ISO 9001:2015 certification known for providing high-quality metal products to industries across the world. Our Coil products of Inconel 601 nickel alloy are produced by using new methods like hot rolling, cold rolling and processes of annealing. Our products meet international standards like ASTM, ASME, DIN, JIS and EN and can be offered in different thicknesses, lengths, and sizes to suit different industries.
Cold Rolled Inconel 601 Coil, Hot Rolled Inconel 601 Coil, Inconel 601 Coil for Furnace Components, Inconel 601 Coil Price, Buy Inconel 601 Coils Online, Inconel 601 Coil Stockist.
Key Features of Inconel 601 Coil
- High-Temperature Oxidation Resistance Superior: Inconel 601 can tolerate more elevated temperatures (up to 1200°C) than Inconel 718 and thus is best used for heat treating equipment.
- Great Surface Stability: Enhances structural integrity even under cyclic thermal conditions.
- Improved Sulfidation Resistance: Performs better than Inconel 718 in sulfur compound exposed environments.
- Lower Carbon Content: Maintains weldability and minimizes the possibility of carbide precipitation.
- Affordable for Thermal Uses: Compared to Inconel 718, Inconel 601 is less expensive and more cost-effective for high temperature applications.
Compositions and Properties of Inconel 601 Coil
The unique chemical composition of Inconel 601 UNS N06601 Coils gives it superior performance in harsh environments. With approximately 61% Nickel, 23% Chromium, and a balanced mix of Iron, Aluminum, and trace elements, this alloy forms a tightly adhering oxide scale that protects it in high-temperature applications. The added aluminum increases resistance to oxidation. Its high nickel content guarantees structural stability, while chromium improves corrosion resistance. This perfect blend enables Alloy 601 Coils to retain strength and resist scaling even after exposure to high heat for extended periods.
Applications of Inconel 601 Coil
Inconel 601 Coil is widely applied in a number of challenging industries owing to its excellent heat and corrosion resistance. These coils are easily used on thermal processing machines, heat exchangers, industrial furnaces and petrochemical refineries. It is also used in aerospace parts, gas turbines and radiant tubes owing to its performance capacity at high stress and high temperatures. The consistency and strength of our Inconel 601 nickel alloy Coil make it an ideal selection where metal fatigue or oxidation might result in expensive failure.
Packaging, Testing & Delivery
Our every Inconel 601 Coil goes through strict quality testing, such as ultrasonic inspection, strict inspection and visual inspection to assure blemish-free delivery. Coils are tightly packed in water-resistant wooden boxes or covered in plastic with edge protection to prevent damage in transit. We provide safe and punctual delivery to domestic and overseas customers with clear marking and documentation for simple handling and tracking. Our packaging is as per the export standards and so your Inconel 601 UNS N06601 Coils reach safely in perfect conditions.
Being one of the prominent Inconel 601 Coils Suppliers, we obtain the finest quality Alloy 601 Coils as per your requirement. Our dedication to excellence, qualified quality standards, and dedicated service make us your best bet for sourcing Inconel 601 Coil. Reach us now for quotations, technical specifications or customized order!
Other Types Inconel 601 Coils
Inconel 601 Hot Rolled Coils
Inconel 601 Cold Rolled Coils
Inconel 601 Polished Coils
Inconel 601 Matt PVC Coils
Inconel 601 Slitting Coils
Inconel Steel 601 Strip Coils
Inconel 601 HR Coils
2B Inconel 601 Coils
Inconel 601 Coils Specification
Specifications: ASTM B409 / ASME SB409
Dimensions: MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc
Size Range: Cold Rolled 0.5-6.4 mm, Hot Rolled 3.0–10.0 mm
Thickness: 0.3 mm to 120 mm.
Width: 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc.
Length: 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Tolerances (width / thickness): EN 10258/ DIN 59381 EN 10151 EN 10088
Form: Sheet, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, soft annealed, descaled, sheared, annealed
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.00 max | 0.50 max | 0.015max | 1.00 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 601 | 2.4851 | N06601 | NCF 601 | NA 49 | XH60BT | NC23FeA | NiCr23Fe |
Inconel 601 Coil Thickness Chart
| Strip Thickness | Width | |||
| 320≤W＜600 | W＜320 | |||
| T1 | T2 | T3 | T4 | |
| T＜0.05 mm | 0.004 | 0.003 | 0.003 | 0.002 |
| 0.05≤T＜0.07 | 0.005 | 0.004 | 0.004 | 0.003 |
| 0.07≤T＜0.08 | 0.006 | 0.005 | 0.005 | 0.003 |
| 0.08≤T＜0.10 | 0.007 | 0.005 | 0.005 | 0.003 |
| 0.10≤T＜0.13 | 0.009 | 0.007 | 0.006 | 0.004 |
| 0.13≤T＜0.15 | 0.010 | 0.008 | 0.007 | 0.004 |
| 0.15≤T＜0.20 | 0.011 | 0.009 | 0.008 | 0.004 |
| 0.20≤T＜0.25 | 0.013 | 0.010 | 0.008 | 0.005 |
| 0.25≤T＜0.30 | 0.015 | 0.011 | 0.009 | 0.005 |
| 0.30≤T＜0.35 | 0.016 | 0.012 | 0.010 | 0.005 |
| 0.35≤T＜0.40 | 0.018 | 0.012 | 0.010 | 0.005 |
| 0.40≤T＜0.50 | 0.020 | 0.015 | 0.012 | 0.005 |
| 0.50≤T＜0.60 | 0.022 | 0.018 | 0.013 | 0.005 |
| 0.60≤T＜0.70 | 0.024 | 0.020 | 0.015 | 0.005 |
| 0.70≤T＜0.80 | 0.026 | 0.022 | 0.017 | 0.005 |
| 0.80≤T＜0.90 | 0.028 | 0.024 | 0.018 | 0.006 |
| 0.90≤T＜1.00 | 0.032 | 0.027 | 0.020 | 0.008 |
| 1.00≤T＜1.20 | 0.035 | 0.030 | 0.022 | 0.008 |
| 1.20≤T＜1.40 | 0.040 | 0.035 | 0.025 | 0.010 |
| 1.40≤T＜1.60 | 0.045 | 0.040 | 0.030 | 0.020 |
Weight Per Inconel 601 Coils
| Thick. on base (millimeter) | Unit Wght / Coil (kilogram) |
| 3000 x1000 x3.0 | 78.0 |
| 3000 x1250 x4.5 | 143.0 |
| 3000 x1250 x6.0 | 180.0 |
| 3000 x1250 x8.0 | 210.0 |
