Buy Inconel 600 Coils Online, WNR 2.4816 Coils, Inconel 600 Coil for Heat Treatment Industry, Nickel Alloy 600 Coil Supplier, Inconel 600 Coil Exporter, Hot Rolled Inconel 600 Coil, Alloy 600 Coils
Nandini Steel is a leading Inconel 600 Coil supplier, with a strong commitment to customer satisfaction and industry-leading standards. Our commitment to excellence is reflected in our ISO 9001:2015 certification where we guarantee the best quality and efficiency in our operations. Inconel alloy 600 Coil is a high-quality alloy that possesses excellent resistance against oxidation, carburization, and corrosion. It is manufactured using advanced processes like cold-rolling and hot-rolling processes, it is designed to work effectively in high-temperature and highly corrosive conditions. The alloy meets the international standards such as ASTM, ASME, DIN, JIS and EN to ensure its reliability and quality in various industrial applications.
Cold Rolled Inconel 600 Coil, Corrosion Resistant Inconel 600 Coil, Inconel 600 Coil Price, ASTM B168 Inconel 600 Coil, Inconel 600 Coil Stockist, High Temperature Inconel 600 Coils, UNS N06600 Coils, Inconel 600 Coils.
Key Features of Inconel 600 Coil
- Improved Corrosion Resistance: Compared to Inconel 625, INCONEL Alloy 600 provides better oxidation resistance, particularly in high-temperature service.
- Increased Thermal Stability: Although Inconel 625 possesses superior mechanical strength because of the inclusion of molybdenum, inconel 600 coil is thermally, more stable in severe heat applications.
- Excellent Weldability: Inconel 600 Coil has superior weldability and fabricability compared to Inconel 625, making it easier to work with.
- Cost-Effectiveness: Inconel 600 Coil provides similar high-temperature resistance at a more economical price than Inconel 625.
Compositions and Properties of Inconel 600 Coil
The unique properties of Inconel 600 Coil are attributed to its specific composition, which includes nickel (72%), chromium (15-17%), and iron (5%). This alloy’s carburization and oxidation resistance, particularly for usage in high-temperature gas and steam conditions. The corrosion resistance is further contributed by chromium content, while nickel base contributes to outstanding strength and resistance to high-temperature oxidation. Strength is further boosted by iron addition, such that Inconel 600 Coil operates well in low and high temperatures. The balance of these elements makes it an exceptional choice for industrial applications where longevity and durability are essential.
Applications of Inconel 600 Coil
The superior properties of Inconel 600 Coil make it suitable for a variety of industries and applications. It is widely utilized in chemical processing, heat exchangers, furnaces, turbine engines, and nuclear reactors, among others. Its ability to withstand high-temperature oxidation and carburization enables it to function in conditions such as industrial furnaces, where other materials would deteriorate. The alloy is also widely utilized in the aerospace and marine sectors, especially in components that are exposed to extreme temperatures. Whether gas turbines or aerospace hardware, Inconel 600 Coil provides longevity, reliability and performance under some of the most severe operating conditions.
Packaging, Testing & Delivery
The coils come in different thicknesses, sizes, and lengths. We provide the utmost care in delivering our Inconel 600 coils, it is properly packaged in a way that prevents them from getting damaged during shipping. Our products are tested rigorously, and they undergo mechanical testing, chemical testing, and dimensional testing to guarantee they meet high standards. We provide Inconel 600 Coil in accordance with ASTM/ASME SB 168 standards, ensuring that our clients have the best material for their needs. We can also provide special packaging and shipping solutions to match particular project specifications.
If you’re looking for a reliable ASTM/ASME SB 168 Exporter, Nandini Steel is your trusted partner. Our commitment to quality and precision ensures that you get top-grade Inconel 600 Coil for any industrial application. Contact us today to get your Inconel Alloy 600 materials at competitive prices and exceptional quality.
Other Types Inconel 600 Coils
Inconel 600 Hot Rolled Coils
Inconel 600 Cold Rolled Coils
Inconel 600 Polished Coils
Inconel 600 Matt PVC Coils
Inconel 600 Slitting Coils
Inconel Steel 600 Strip Coils
Inconel 600 HR Coils
2B Inconel 600 Coils
Inconel 600 Coils Specification
Specifications: ASTM B409 / ASME SB409
Dimensions: MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc
Size Range: Cold Rolled 0.5-6.4 mm, Hot Rolled 3.0–10.0 mm
Thickness: 0.3 mm to 120 mm.
Width: 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc.
Length: 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Tolerances (width / thickness): EN 10258/ DIN 59381 EN 10151 EN 10088
Form: Sheet, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, soft annealed, descaled, sheared, annealed
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
Inconel 600 Coil Thickness Chart
| Strip Thickness | Width | |||
| 320≤W＜600 | W＜320 | |||
| T1 | T2 | T3 | T4 | |
| T＜0.05 mm | 0.004 | 0.003 | 0.003 | 0.002 |
| 0.05≤T＜0.07 | 0.005 | 0.004 | 0.004 | 0.003 |
| 0.07≤T＜0.08 | 0.006 | 0.005 | 0.005 | 0.003 |
| 0.08≤T＜0.10 | 0.007 | 0.005 | 0.005 | 0.003 |
| 0.10≤T＜0.13 | 0.009 | 0.007 | 0.006 | 0.004 |
| 0.13≤T＜0.15 | 0.010 | 0.008 | 0.007 | 0.004 |
| 0.15≤T＜0.20 | 0.011 | 0.009 | 0.008 | 0.004 |
| 0.20≤T＜0.25 | 0.013 | 0.010 | 0.008 | 0.005 |
| 0.25≤T＜0.30 | 0.015 | 0.011 | 0.009 | 0.005 |
| 0.30≤T＜0.35 | 0.016 | 0.012 | 0.010 | 0.005 |
| 0.35≤T＜0.40 | 0.018 | 0.012 | 0.010 | 0.005 |
| 0.40≤T＜0.50 | 0.020 | 0.015 | 0.012 | 0.005 |
| 0.50≤T＜0.60 | 0.022 | 0.018 | 0.013 | 0.005 |
| 0.60≤T＜0.70 | 0.024 | 0.020 | 0.015 | 0.005 |
| 0.70≤T＜0.80 | 0.026 | 0.022 | 0.017 | 0.005 |
| 0.80≤T＜0.90 | 0.028 | 0.024 | 0.018 | 0.006 |
| 0.90≤T＜1.00 | 0.032 | 0.027 | 0.020 | 0.008 |
| 1.00≤T＜1.20 | 0.035 | 0.030 | 0.022 | 0.008 |
| 1.20≤T＜1.40 | 0.040 | 0.035 | 0.025 | 0.010 |
| 1.40≤T＜1.60 | 0.045 | 0.040 | 0.030 | 0.020 |
Weight Per Inconel 600 Coils
| Thick. on base (millimeter) | Unit Wght / Coil (kilogram) |
| 3000 x1000 x3.0 | 78.0 |
| 3000 x1250 x4.5 | 143.0 |
| 3000 x1250 x6.0 | 180.0 |
| 3000 x1250 x8.0 | 210.0 |
